- Artikelnummer
- B 80
- Woofer Series
- High-End
- Woofer Type
- Full-Range
- Nominal Diameter
- 3.3"
- Power Handling (RMS)
- 30 Watts
- Power Handling (max)
- 50 Watts
- Impedance
- 8 ohms
- Sensitivity
- 85 dB (1 W/1 m)
- Frequency Response
- 80 - 20,000 Hz
- Voice Coil Diameter
- 25 mm
- DC Resistance (Re)
- 6.6 ohms
- Resonant Frequency (Fs)
- 110 Hz
- Mechanical Q (Qms)
- 6.53
- Electromagnetic Q (Qes)
- 0.69
- Total Q (Qts)
- 0.63
- Mechanical Compliance of Suspension (Cms)
- 0.87 mm/N
- Surface Area of Cone (Sd)
- 38.5 cm2
- BL Product (BL)
- 4.15 Tm
- Maximum Linear Excursion (Xmax)
- 2.25 mm
- Cone / Diaphragm Material
- Treated Paper
- Surround Material
- Rubber
- Overall Outside Diameter
- 104.4 mm
- Overall Depth
- 49.3 mm
- Baffle Cutout Diameter
- 89 mm
- Bolt Circle Diameter
- 95 mm
- # Mounting Holes
- 4
- Mounting Hole Diameter
- 3.9 mm
