    SEAS Excel W16NX001 - E0049-08 6" Magnesium Cone Woofer

    € 249,95 2 Op voorraad: levertijd 1 werkdag
    Precision cast, machined and surface treated magnesium cone acts as a piston through the audible frequency band without showing any sign of midrange resonances. A unique radial reinforced rubber surround reduces radial resonances and prevents surround bre... Toon meer
    Volume voordeel Geniet van deze geweldige kortingsdeals
    • -5% Bestel 4 voor slechts €237,45 per stuk
    • Gratis verzending vanaf €99,
    • Voor 16u besteld, vandaag verstuurd*
    • Betaal met IDEAL, PayPal en meer
    • In-house technische support

    Productomschrijving

    Highlights

    • Long term power handling (RMS) is 80 Watts
    • Unique radial reinforced rubber surround reduces radial resonances and prevents surround break up at large excursions
    • Reduced compression, increased long term power handling capacity and eliminated resonances in the cavity inside the voice coil former



    Product details

    Seas Excel W16NX001 - E0049-08 6" Magnesium Cone Woofer



    Precision cast, machined and surface treated magnesium cone acts as a piston through the audible frequency band without showing any sign of midrange resonances. A unique radial reinforced rubber surround reduces radial resonances and prevents surround break up at large excursions.



    Heavy copper rings mounted above and below the T-shaped pole piece reduce non linear and modulation distortion and increase overload margin. A copper phase plug reduces compression due to temperature variations in the voice coil, increases long term power handling capacity and eliminates resonances in the cavity inside the voice coil former.



    The extremely stiff and stable injection molded metal basket keeps the critical components in perfect alignment. Large windows in the basket both above and below the spider reduce sound reflection, air flow noise and cavity resonance to a minimum.

    Specificaties

    Artikelnummer
    W16NX001
    Woofer Series
    Excel Series
    Woofer Type
    Midwoofer
    Nominal Diameter
    6"
    Power Handling (RMS)
    80 Watts
    Power Handling (max)
    250 Watts
    Impedance
    8 ohms
    Sensitivity
    85 dB 2.83V/1m
    Frequency Response
    45 to 2,500 Hz
    Voice Coil Diameter
    1.49"
    Magnet Weight
    22.5 oz.
    DC Resistance (Re)
    6.2 ohms
    Voice Coil Inductance (Le)
    0.41 mH
    Resonant Frequency (Fs)
    39 Hz
    Mechanical Q (Qms)
    2.16
    Electromagnetic Q (Qes)
    0.41
    Total Q (Qts)
    0.35
    Diaphragm Mass Inc. Airload (Mms)
    13.9g
    Mechanical Compliance of Suspension (Cms)
    1.2 mm/N
    Compliance Equivalent Volume (Vas)
    0.49 ft.³
    Maximum Linear Excursion (Xmax)
    7 mm
