Prestige ER15RLY - H1455-08 Bass-midwoofer

€109,95

Toevoegen aan winkelwagen

SEAS Prestige ER15RLY - H1455-08 Bass-midwoofer

1 reviews

Merk: SEAS

Toon alle Bass-mid woofer

5.5" | 8 Ω

Prestige ER15RLY - H1455-08 Bass-midwoofer

€ 90,87€ 109,95 10+ Op voorraad

Gratis verzonden (NL & BE)
Nu besteld, morgen verstuurd
Ten minste twee jaar garantie
45 dagen bedenktijd voor retourneren

Klantbeoordeling:

Vergelijk

Zakelijke offerteaanvraag

Heeft u vragen over dit product?

Onze klantenservice helpt u graag verder!

Productomschrijving

Highlights

Developed for use as a long throw high fidelity woofer or woofer/midrange unit
Smooth, extended frequency response
Good coil excursion with low distortion and good transient response

Product details

Seas Prestige ER15RLY - H1455-08 5.5" Reed Paper Cone Woofer

The ER15RLY is a 5" cone driver, developed for use as a long throw high fidelity woofer or woofer/midrange unit. Edge coated reed/paper pulp cone, together with perfectly matched moving parts gives a smooth, extended frequency response.

Large magnet system, together with a very long and light weight copper clad aluminum voice coil allow good coil excursion with low distortion and good transient response. Extremely stiff and stable injection molded metal basket keeps the critical components in perfect alignment. Large windows in the basket both above and below the spider reduce sound reflection, air flow noise and cavity resonance to a minimum.

Toon meer

Specificaties

Artikelnummer: ER15RLY
Woofer series: Prestige Series
Woofer type: Midwoofer
Nominale diameter: 5.5"
Belastbaarheid (RMS): 60 Watts
Belastbaarheid (max): 250 Watts
Impedantie (Z): 8 ohms
Gevoeligheid (SPL bij 1m / 2.83V): 87.5 dB
Frequentierespons: 50 to 4,000 Hz
Spreekspoeldiameter: 1"
Gewicht magneet: 14 oz.
Gelijkstroomweerstand (Re): 5.6 ohms
Spreekspoelinductie (Le): 0.73 mH
Resonantiefrequentie (Fs): 44 Hz
Mechanische Q (Qms): 1.55
Elektrische Q (Qes): 0.41
Totale Q (Qts): 0.32
Bewegende massa (Mms): 7.6g
Compliantie van de ophanging (Cms): 1.7 mm/N
Equivalentvolume (Vas): 0.52 ft.³
Maximale excursie (Xmax): 5 mm
Totale buitendiameter: 5.75"
Totale diepte: 2.82"
Montagegatdiameter: 4.41"
Bolt Circle Diameter: 5.37"
# Bevestigingsgaten: 6
Diameter bevestigingsgaten: 0.2"

Reviews

1 reviews

Schrijf een review

5 van 5

This is not a speaker It's a miracle.
It sounds amazing as full range, ok it has not enough high frequencies, but everything comes out from this speaker is wonderfull.
I bought this speaker by mistake, but now I know I'm a lucky guy.
I'm going to build a great bookshelf in union with the Audio Note silver tweeter.
As always Seas proves his value. 10+++++

Door Bruno P. on 16 Juni 2020
