        Prestige 27TBFC/G - H1212-06 1'' Aluminum Dome Tweeter

        SEAS Prestige 27TBFC/G - H1212-06 1'' Aluminum Dome Tweeter

        €71,45

        10+ Op voorraad

        SEAS Prestige 27TBFC/G - H1212-06 1'' Aluminum Dome Tweeter

        17 reviews
        5 van 5
        17 reviews
        5 sterren
        82%
        4 sterren
        12%
        3 sterren
        6%
        2 sterren
        0%
        1 ster
        0%
        Bekijk alle reviews
        Merk: SEAS
        € 59,05€ 71,45 10+ Op voorraad
        • -5% Bestel 4 voor slechts € 67,88 per stuk

        Buy now, pay later

        • Gratis verzending vanaf € 99
        • Nu besteld, dinsdag bezorgd
        • Ten minste twee jaar garantie
        • 45 dagen bedenktijd voor retourneren
        • Klantbeoordeling:
        Zakelijke offerteaanvraag
        Heeft u vragen over dit product?

        Heeft u vragen over dit product?

        Onze klantenservice helpt u graag verder!

        Productomschrijving SEAS Prestige 27TBFC/G - H1212-06 Dome Tweeter

        Highlights

        • Aluminum/magnesium alloy diaphragm with pistonic behavior throughout the audible frequency range, resulting in a good dispersion above 10kHz
        • 90 Watts RMS Power Handling
        • 91.5 dB 2.83V/1m Sensitivity



        Product details

        Seas Prestige 27TBFC/G - H1212-06 1'' Aluminum Dome Tweeter



        The 27TBFC/G is a High Definition metal dome tweeter with a wide, soft polymer surround and a rear chamber. Aluminum/magnesium alloy diaphragm with pistonic behavior throughout the audible frequency range, resulting in a good dispersion also above 10kHz. A Hexagrid protects the diaphragm and supports a phase plate which compensates for a slight axial roll off towards 20 kHz. Sonomax surround for low resonance and excellent mechanical linearity.



        Voice coil windings immersed in magnetic fluid increase short term power handling capacity and reduce the compression at high power levels. Stiff and stable rear chamber with optimal acoustic damping allows the tweeter to be used with moderately low crossover frequencies.



        Precision molded chassis from glass fiber reinforced plastic, and its front design offers optimum radiation conditions.

        Toon meer

        Specificaties

        Artikelnummer
        27TBFC/G
        EAN
        0696277269761
        Tweeter type
        Dome)
        Cone / Dome Diameter
        26 mm | 1"
        Belastbaarheid (RMS)
        90 Watts
        Impedantie (Z)
        6 Ω
        Gevoeligheid (SPL bij 1m / 2.83V)
        91.5 dB
        Frequentierespons
        1.500 - 20.000 Hz
        Resonantiefrequentie (Fs)
        550 Hz
        Gelijstroomweerstand (Re)
        4.8 ohms
        Voice Coil Inductance (Le)
        0.05 mH
        Totale buitendiameter
        103.8 mm
        Montagegatdiameter
        85 mm
        Diepte
        42.5 mm
        Membraan materiaal
        Aluminium-Magnesium

        Toon meer

        5 van 5
        The pair of SEAS tweeters purchased were to directly replace a faulty pair in my transmission line speakers. Therefore I required a direct replacement with the same dimensional & electrical characteristics. So the product purchased was ideal.
        Door Dennis on 20 Augustus 2025
        5 van 5
        It’s to soon to gave useful opinion, but still even now outside the box it plays nice. It got potential.
        Door Matej on 30 Januari 2025
