        Classic D2905/970000 1” Dome Tweeter 6 Ohms

        Classic D2905/970000 1” Dome Tweeter 6 Ohms

        €164,95

        Scan-Speak Classic D2905/970000 1” Dome Tweeter 6 Ohms

        1 reviews
        5 van 5
        1 reviews
        5 sterren
        100%
        4 sterren
        0%
        3 sterren
        0%
        2 sterren
        0%
        1 ster
        0%
        Bekijk alle reviews
        € 136,32€ 164,95 10+ Op voorraad
        • -5% Bestel 4 voor slechts € 156,70 per stuk

        Buy now, pay later

        • Gratis verzonden (NL & BE)
        • Nu besteld, dinsdag bezorgd
        • Ten minste twee jaar garantie
        • 45 dagen bedenktijd voor retourneren
        • Klantbeoordeling:
        Zakelijke offerteaanvraag
        Heeft u vragen over dit product?

        Heeft u vragen over dit product?

        Onze klantenservice helpt u graag verder!

        Productomschrijving

        Highlights

        • Patented Symmetrical Drive (SD-2) motor
        • Hand coated 1" Textile Dome Diaphragm
        • Low Resonance Rear Chamber
        • Black Aluminium Face Plate
        • Low viscosity Ferro Fluid



        Product Details

        Scan-Speak D2905/970000 1” Dome Tweeter 6 Ohms



        The Scanspeak D2905/970000 has a high power handling of 225W and a frequency response of above 30KHz. Features include a hand-coated 25mm soft textile dome, an airflow optimized copper capped pole piece and a tuned rear chamber with an integral resonance damping plug.



        This tweeter also benefits from the Scanspeak SD2 'Symmetrical Drive' system incorporating a copper capped and sleeved center pole piece;  this effectively forms a very low impedance shorted turn (called a Faraday ring) within the magnet circuit, the net result being that the voice coil impedance remains largely constant across it's operating frequency range resulting in a more linear output with greater top-end extension.



        This is a highly advanced design with a sweet, detailed sound. Found in many high-end designs and is a top choice for DIY high-performance loudspeakers.

        Toon meer

        Specificaties

        Artikelnummer
        D2905/970000
        Cone / Dome Diameter
        25 mm | 1"
        Belastbaarheid (RMS)
        225 Watts
        Impedantie (Z)
        6 Ω
        Gevoeligheid (SPL bij 1m / 2.83V)
        89.5 dB
        Resonantiefrequentie (Fs)
        500 Hz
        Gelijstroomweerstand (Re)
        5.7 ohms
        Voice Coil Inductance (Le)
        0.01 mH
        Mechanische Q (Qms)
        3.45
        Electromagnetic Q (Qes)
        0.54
        Totale Q (Qts)
        0.47
        Totale buitendiameter
        104.3 mm
        Montagegatdiameter
        75 mm
        Diepte
        40.7 mm
        Bevestigingstype
        Screw
        Membraan materiaal
        Textile

        Toon meer

        5 van 5
        Super, fast delivery.
        Door David Drimal on 12 Maart 2024
