        Revelator D2904/710002 1" Coated Textile Dome Tweeter

        Revelator D2904/710002 1" Coated Textile Dome Tweeter

        €319,95

        Scan-Speak Revelator D2904/710002 1" Coated Textile Dome Tweeter

        1 reviews
        5 van 5
        1 reviews
        5 sterren
        100%
        4 sterren
        0%
        3 sterren
        0%
        2 sterren
        0%
        1 ster
        0%
        Bekijk alle reviews
        € 264,42€ 319,95 5 Op voorraad
        2 variaties D2904/710002
        • -5% Bestel 4 voor slechts € 303,95 per stuk

        Buy now, pay later

        • Gratis verzonden (NL & BE)
        • Nu besteld, morgen bezorgd
        • Ten minste twee jaar garantie
        • 45 dagen bedenktijd voor retourneren
        • Klantbeoordeling:
        Zakelijke offerteaanvraag
        Heeft u vragen over dit product?

        Heeft u vragen over dit product?

        Onze klantenservice helpt u graag verder!

        Productomschrijving

        Highlights

        • 1" Coated Textile Diaphragm
        • Patented Symmetrical Drive (SD-2) motor
        • Non Resonant Alu Rear Chamber
        • Large Roll Surround for Wide Dispersion
        • Large Ring Neo Magnet for High Output
        • Silver Anodized Machined Alu Face Plate



        Product details

        Scan-Speak Revelator D2904/710002 1" Coated Textile Dome Tweeter



        The Scan-speak D2904-710002 tweeter is a 1" soft dome with wide surround, using the same chambering as the Ring Radiator.



        The carefully designed dome and surround result in a linear response and an exceptionally good off axis response. Note the smooth roll off on the low end, making this tweeter an excellent choice for simple slopes. A specially designed venting system uses a needle to cut down on turbulence in the air cavity. Better dynamics are achieved by not using ferrofluid, voice coil cooling is performed by the venting system and conduction through copper rings. The new SD-2 neodymium magnet system improves transient response.



        Specifications: Compliance Equivalent Volume (Vas): 0.0007 ft.³ • BL Product (BL): 2.8 Tm • Mechanical Compliance of Suspension (Cms): 0.23 mm/N • Diaphragm Mass Inc. Airload (Mms): 0.4 g • Maximum Linear Excursion (Xmax): 0.2 mm • Surface Area of Cone (Sd): 7 cm2

        Toon meer

        Specificaties

        Artikelnummer
        D2904/710002
        Tweeter type
        Dome
        Tweeter serie
        Revelator Series
        Cone / Dome Diameter
        25 mm | 1"
        Belastbaarheid (RMS)
        90 Watts
        Power Handling (max)
        150 Watts
        Impedantie (Z)
        4 Ω
        Gevoeligheid (SPL bij 1m / 2.83V)
        94.4 dB
        Resonantiefrequentie (Fs)
        520 Hz
        Gelijstroomweerstand (Re)
        3 ohms
        Voice Coil Inductance (Le)
        0.01 mH
        Mechanische Q (Qms)
        3.50
        Electromagnetic Q (Qes)
        0.50
        Totale Q (Qts)
        0.44

        Toon meer
