    Scan-Speak 5F/8422T01 2'' Full Range Driver

    € 56,95 Niet op voorraad: binnen 1 week leverbaar
    The Discovery series offer traditional design, superior sound, a solid construction, and a wide range of variants. Combining these elements - plus a wealth of technical features and finesses - gives our customers the possibility of acquiring a tailor-made... Toon meer
    Volume voordeel Geniet van deze geweldige kortingsdeals
    • -5% Bestel 4 voor slechts €54,10 per stuk
    • Gratis verzending vanaf €99,
    • Voor 16u besteld, vandaag verstuurd*
    • Betaal met IDEAL, PayPal en meer
    • In-house technische support

    Productomschrijving

    The Discovery series offer traditional design, superior sound, a solid construction, and a wide range of variants. Combining these elements - plus a wealth of technical features and finesses - gives our customers the possibility of acquiring a tailor-made Scan-Speak solution with very good performance at a reasonable low price point!



    Highlights

    • Powerful Neo Ring Motor, Symmetric Drive
    • 1" Voice Coil, Ti Former, European Soft Parts
    • Paper Cone, Foam Surround, Long Excursion
    • Large Pole Piece Vent, Low Distortion
    • Wide Frequency Range
    • Extended Copper Cap on Pole Piece



    Product details

    Scan-Speak 5F/8422T01 2'' Full Range Driver



    The Discovery series offer traditional design, superior sound, a solid construction, and a wide range of variants. Combining these elements - plus a wealth of technical features and finesses - gives our customers the possibility of acquiring a tailor-made Scan-Speak solution with very good performance at a reasonable low price point! The Scan-Speak 5F/8422T01 Full Range Driver boasts all the good stuff that you are used to seeing when looking at a Scan-Speak driver. A powerful motor, well designed soft parts and low distortion.

    Specificaties

    Artikelnummer
    5F/8422T01
    Woofer Series
    Discovery Series
    Woofer Type
    Full-range
    Nominal Diameter
    2"
    Power Handling (RMS)
    10 Watts
    Power Handling (max)
    20 Watts
    Impedance
    8 ohms
    Sensitivity
    80 dB 2.83V/1m
    Frequency Response
    100 to 20,000 Hz
    Voice Coil Diameter
    1"
    DC Resistance (Re)
    6.0 ohms
    Voice Coil Inductance (Le)
    0.07 mH
    Resonant Frequency (Fs)
    93 Hz
    Mechanical Q (Qms)
    5.17
    Electromagnetic Q (Qes)
    0.69
    Total Q (Qts)
    0.61
    Diaphragm Mass Inc. Airload (Mms)
    1.86g
    Mechanical Compliance of Suspension (Cms)
    1.58 mm/N
    Surface Area of Cone (Sd)
    15.2 cm²
    BL Product (BL)
    3.07 Tm
    Compliance Equivalent Volume (Vas)
    0.02 ft.³
    Maximum Linear Excursion (Xmax)
    2 mm
    Driver's Mechanical Losses (Rms)
    0.21 kg/s
    Cone / Diaphragm Material
    Paper
    Surround Material
    Foam
    Voice Coil Former
    Titanium
    Dual Voice Coil
    No
    Basket / Frame Material
    Aluminum
    Magnet Material
    Neodymium
    Shielded
    No
    Overall Outside Diameter
    2.64''
    Overall Depth
    1.30''
    Baffle Cutout Diameter
    2.11''
    Bolt Circle Diameter
    2.38''
    # Mounting Holes
    4
    Mounting Hole Diameter
    0.13''

    Reviews

    5 from 5Based on 2 reviews
    Schrijf een review
    4 van 5
    Sounds incredibly full for such a tiny speaker!
    The foam surround could be an issue but still its very high quality foam, it will last quite a while.
    One thing I have to complaint is, that the basket is made out of plastic not that it would bad but if you try to solder the wires on the terminal, the plastic will melt veeery quickly, the plastic is pretty soft too so be careful with that.
    Also what has happened is that the magnet has come loose! I really am very careful with my speakers but this is the second time this ever happened to me.
    But no problem, I glued it carefully back, still is fine.
    Overall opinion:
    Very full bodied sound, balanced, great excursion, simply Scan-Speak sound.
    But its very fragile, it can break easily, however builtquality is great.
    Door GIZMO320 on 23 Januari 2021
    5 van 5
    Koper heeft geen omschrijving achtergelaten.
    Door Derk Jan R. on 13 Maart 2020
