        NERO-5CCN125D Mid-range Woofer

        SB Audience NERO-5CCN125D Mid-range Woofer

        €169,95

        Niet op voorraad

        Toevoegen aan winkelwagen

        SB Audience NERO-5CCN125D Mid-range Woofer

        0 reviews
        0 van 5
        0 reviews
        5 sterren
        0%
        4 sterren
        0%
        3 sterren
        0%
        2 sterren
        0%
        1 ster
        0%
        Bekijk alle reviews
        Merk: SB Audience
        Toon alle Nieuwe producten
        5" | 8 Ω
        NERO-5CCN125D Mid-range Woofer
        NERO-5CCN125D Mid-range Woofer
        NERO-5CCN125D Mid-range Woofer
        NERO-5CCN125D Mid-range Woofer
        NERO-5CCN125D Mid-range Woofer
        NERO-5CCN125D Mid-range Woofer
        NERO-5CCN125D Mid-range Woofer
        NERO-5CCN125D Mid-range Woofer
        NERO-5CCN125D Mid-range Woofer
        NERO-5CCN125D Mid-range Woofer
        € 140,45€ 169,95 Niet op voorraad
        • -5% Bestel 4 voor slechts € 161,45 per stuk
        +-
        Toevoegen aan winkelwagen

        Buy now, pay later

        • Gratis verzonden (NL & BE)
        • Snel weer op voorraad
        • Ten minste twee jaar garantie
        • 45 dagen bedenktijd voor retourneren
        • Klantbeoordeling:
        Zakelijke offerteaanvraag
        Heeft u vragen over dit product?

        Heeft u vragen over dit product?

        Onze klantenservice helpt u graag verder!

        NERO-5CCN125D Mid-range Woofer
        NERO-5CCN125D Mid-range Woofer
        NERO-5CCN125D Mid-range Woofer
        NERO-5CCN125D Mid-range Woofer
        NERO-5CCN125D Mid-range Woofer
        NERO-5CCN125D Mid-range Woofer
        NERO-5CCN125D Mid-range Woofer
        NERO-5CCN125D Mid-range Woofer
        NERO-5CCN125D Mid-range Woofer
        NERO-5CCN125D Mid-range Woofer

        Voor- en nadelen

        Volgens onze specialisten
        • Removable cast aluminum rear chamber
        • Suitable for high compression midrange applications

        Productomschrijving SB Audience NERO-5CCN125D Mid-range Woofer

        High-efficiency 5-inch midrange driver built for demanding audio environments. The NERO-5CCN125D delivers outstanding clarity and low distortion, making it ideal for high-compression midrange applications in both professional and high-end DIY setups.



        Highlights of the NERO NERO-5CCN125D

        • 99 dB sensitivity with wide frequency response (355 – 20,000 Hz)
        • Robust 125W AES power handling, 250W max power
        • Neodymium magnet and copper sleeve for reduced distortion
        • Removable rear chamber with die-cast aluminum basket



        Product details NERO NERO-5CCN125D

        NERO NERO-5CCN125D 5” Midrange Loudspeaker



        The NERO-5CCN125D is a 5-inch high-efficiency midrange driver engineered for precision and low distortion in professional sound systems and advanced DIY loudspeaker projects. With a powerful neodymium magnet and copper sleeve demodulation ring, it maintains low inductance and minimizes intermodulation distortion. Its pure carbon fiber cone and inverted low-mass surround deliver exceptional midrange clarity. This driver handles 125W AES and up to 250W peak power while achieving up to 99 dB sensitivity (with chamber) at 2.83V/1m.



        The robust cast aluminum chassis supports a removable rear chamber, enhancing its flexibility for varied cabinet designs. It incorporates a 38.5 mm voice coil wound with copper-clad aluminum on a fiberglass former, allowing it to perform reliably under high thermal loads. Key technical parameters include a resonant frequency (Fs) of 122 Hz (without chamber), Xmax of 3.2 mm, and a net air volume displacement of 0.59 liters. Its optimized Thiele-Small parameters make it suitable for high-efficiency midrange horn or sealed applications where space and sound pressure level are critical.

        Toon meer

        Specificaties

        Artikelnummer
        NERO-5CCN125D
        EAN
        9502219616931
        Woofer type
        Mid Range Woofer
        Nominale diameter
        5”
        Belastbaarheid (RMS)
        125 Watts
        Belastbaarheid (max)
        250 Watts
        Impedantie (Z)
        8 Ω
        Gevoeligheid (SPL bij 1m / 2.83V)
        Chamber 99 dB. no chamber 97 dB
        Frequentierespons
        355 - 20.000 Hz
        Spreekspoeldiameter
        38.5 mm
        Gelijkstroomweerstand (Re)
        5.4 Ω
        Spreekspoelinductie (Le)
        Chamber 0.03 mH, No chamber 0.07 mH
        Resonantiefrequentie (Fs)
        Chamber 360 Hz, No chamber 122 Hz
        Mechanische Q (Qms)
        Chamber 16.6, No chamber 9.61
        Elektrische Q (Qes)
        Chamber 0.76, No chamber 0.28
        Totale Q (Qts)
        Chamber 0.73, No chamber 0.28
        Bewegende massa (Mms)
        7.9 g
        Compliantie van de ophanging (Cms)
        Chamber 0.03 mm/N, No chamber 0.22 mm/N
        Effectief oppervlak (Sd)
        93.3 cm²
        Krachtsfactor (BL)
        10.6 Tm
        Equivalentvolume (Vas)
        Chamber 0.3 Liters, No chamber 2.70 Liters
        Maximale excursie (Xmax)
        3.2 mm
        Spreekspoel vormermateriaal
        Till
        Magneetmateriaal
        Neodymium
        Totale buitendiameter
        159 mm
        Montagegatdiameter
        Chamber 125 mm. No chamber 120.3 mm
        Bolt Circle Diameter
        142 mm
        # Bevestigingsgaten
        4
        Diameter bevestigingsgaten
        4 mm
