    SB Acoustics Satori WO24P-4 9.5" Egyptian Papyrus Cone Woofer

    € 184,95 2 Op voorraad: levertijd 1 werkdag
    The Satori range was founded to separate more expensive projects from a wider range of more affordable – but still high-end – SB Acoustics products. As we get more experience, new materials, better simulation tools, we believe in benefiting the customer w... Toon meer
    Volume voordeel Geniet van deze geweldige kortingsdeals
    • -5% Bestel 4 voor slechts €175,70 per stuk
    • Gratis verzending vanaf €99,
    • Voor 16u besteld, vandaag verstuurd*
    • Betaal met IDEAL, PayPal en meer
    • In-house technische support

    Productomschrijving

    Highlights

    • Hard paper cone for improved piston operation (made in-house)
    • Large optimized motor system with under-cut pole piece and dual shorting rings
    • Vented aerodynamic cast aluminum chassis for optimum strength and low compression
    • Soft low damping rubber surround for optimum transient response
    • Linear symmetric suspension design for improved dynamic performance
    • Non-conducting fibrer glass voice coil former for minimum damping
    • Long life silver lead wires attached 180° apart for improved stability
    • Vented pole piece for reduced compression
    • High piston to chassis diameter ratio
    • Gasket and bolt hole protrusions for reduced coupling to speaker cabinet



    Product details

    SB Acoustics Satori WO24P-4 9.5" Egyptian Papyrus Cone Woofer



    The Satori range was founded to separate more expensive projects from a wider range of more affordable – but still high-end – SB Acoustics products. “As we get more experience, new materials, better simulation tools, we believe in benefiting the customer with those improvements. We always knew that geometry is essential and we are working more and more with geometry. Every time we get new materials, like beryllium, and we optimize the designs, there’s always room for improvement. We’ve been able to implement significant improvements with beryllium, and we could obtain pretty good results in combination with geometry.”

    Specificaties

    Artikelnummer
    WO24P-4
    Woofer Series
    Satori Series
    Woofer Type
    Midwoofer
    Nominal Diameter
    9.5"
    Power Handling (RMS)
    90 Watts
    Impedance
    4 ohms
    Sensitivity
    91 dB 2.83V/1m
    Voice Coil Diameter
    1.94"
    DC Resistance (Re)
    3.3 ohms
    Voice Coil Inductance (Le)
    0.29 mH
    Resonant Frequency (Fs)
    28 Hz
    Mechanical Q (Qms)
    6.7
    Electromagnetic Q (Qes)
    0.42
    Total Q (Qts)
    0.40
    Diaphragm Mass Inc. Airload (Mms)
    42 g
    Mechanical Compliance of Suspension (Cms)
    0.77 mm/N
    Surface Area of Cone (Sd)
    255 cm2
    BL Product (BL)
    7.6 Tm
    Compliance Equivalent Volume (Vas)
    2.50 ft.³
    Maximum Linear Excursion (Xmax)
    8.5 mm

    Reviews

    5 from 5Based on 1 reviews
    Schrijf een review
    5 van 5
    Incredible well build driver, for being so shallow, it can handle a veeery decent excursion while producing very little mechanical noises.
    Its also pretty efficient, doesent need lots of power to get this subwoofer going.
    Door GIZMO320 on 8 Januari 2021
