        Productomschrijving SB Acoustics SB17NRX2L35-4 Bass-midwoofer

        High-performance 6" 4-ohm midwoofer from SB Acoustics featuring a natural fiber cone, precision motor design, and vented aluminum chassis for clean and dynamic sound reproduction.



        Highlights of the SB Acoustics SB17NRX2L35-4

        • Robust vented cast aluminum chassis for high rigidity and reduced compression
        • Natural fiber proprietary cone ensures a balanced and detailed tonal response
        • High-efficiency 4-ohm voice coil with low inductance (0.14 mH) for accurate transient handling
        • Advanced motor system with extended copper sleeve and vented coil former



        Product details SB Acoustics SB17NRX2L35-4

        SB Acoustics SB17NRX2L35-4 6" 4-Ohm Midwoofer



        The SB Acoustics SB17NRX2L35-4 is a 6-inch midwoofer optimized for applications demanding high sensitivity and low distortion. Designed around a vented cast aluminum chassis, it provides excellent mechanical stability while minimizing acoustic compression. The cone, made from a proprietary natural fiber blend, delivers smooth and natural frequency response with very low coloration. This 4-ohm variant uses a CCAW voice coil on a non-conductive fiberglass former to reduce moving mass and electrical damping. An extended copper sleeve in the large motor structure ensures low inductance and improved linearity across the range. Additional ventilation on the coil former and pole piece enhances thermal handling and reduces dynamic compression. With a sensitivity of 92 dB (2.83 V / 1 m), free air resonance at 41 Hz, and rated power handling of 60 W, the SB17NRX2L35-4 is ideal for high-efficiency loudspeaker designs and compact two-way systems where dynamic range and tonal accuracy are critical.

        Toon meer

        Specificaties

        Artikelnummer
        SB17NRX2L35-4
        EAN
        9503895618721
        Belastbaarheid (RMS)
        60 Watts
        Gelijkstroomweerstand (Re)
        3.1 ohms
        Spreekspoelinductie (Le)
        0.14 mH
        Resonantiefrequentie (Fs)
        41 Hz
        Mechanische Q (Qms)
        4.97
        Elektrische Q (Qes)
        0.26
        Totale Q (Qts)
        0.25
        Bewegende massa (Mms)
        13.5g
        Compliantie van de ophanging (Cms)
        1.1 mm/N
        Effectief oppervlak (Sd)
        118 cm²
        Krachtsfactor (BL)
        6.45 N/A
        Equivalentvolume (Vas)
        21.9 Liters
        Maximale excursie (Xmax)
        4.8 mm
