        SB17NRX2C35-4 Norex Bass-midwoofer

        SB17NRX2C35-4 Norex Bass-midwoofer

        €72,45

        Toevoegen aan winkelwagen

        SB Acoustics SB17NRX2C35-4 Norex Bass-midwoofer

        0 reviews
        0 van 5
        0 reviews
        5 sterren
        0%
        4 sterren
        0%
        3 sterren
        0%
        2 sterren
        0%
        1 ster
        0%
        Bekijk alle reviews
        Merk: SB Acoustics
        Toon alle Nieuwe producten
        6.5" | 4 Ω
        SB17NRX2C35-4 Norex Bass-midwoofer
        SB17NRX2C35-4 Norex Bass-midwoofer
        SB17NRX2C35-4 Norex Bass-midwoofer
        SB17NRX2C35-4 Norex Bass-midwoofer
        SB17NRX2C35-4 Norex Bass-midwoofer
        SB17NRX2C35-4 Norex Bass-midwoofer
        SB17NRX2C35-4 Norex Bass-midwoofer
        SB17NRX2C35-4 Norex Bass-midwoofer
        € 59,88€ 72,45 6 Op voorraad10+ verwacht op 24-05-2024
        • -5% Bestel 4 voor slechts € 68,83 per stuk
        +-
        Toevoegen aan winkelwagen

        Buy now, pay later

        • Gratis verzending vanaf € 99
        • Nu besteld, morgen verstuurd
        • Ten minste twee jaar garantie
        • 45 dagen bedenktijd voor retourneren
        • Klantbeoordeling:
        Zakelijke offerteaanvraag
        Heeft u vragen over dit product?

        Heeft u vragen over dit product?

        Onze klantenservice helpt u graag verder!

        SB17NRX2C35-4 Norex Bass-midwoofer
        SB17NRX2C35-4 Norex Bass-midwoofer
        SB17NRX2C35-4 Norex Bass-midwoofer
        SB17NRX2C35-4 Norex Bass-midwoofer
        SB17NRX2C35-4 Norex Bass-midwoofer
        SB17NRX2C35-4 Norex Bass-midwoofer
        SB17NRX2C35-4 Norex Bass-midwoofer
        SB17NRX2C35-4 Norex Bass-midwoofer

        Productomschrijving

        The SB Acoustics SB17NRX2C35-4 is a 6.5'' (171mm) bass-midwoofer that has a nominal impedance of 4 Ω and a voice coil diameter of 35.5 mm. It has an effective piston area of 118 cm² and a voice coil height of 16 mm. The speaker has a free air resonance of 36 Hz and a sensitivity of 90 dB (2.83V/1m).



        Highlights

        • Vented cast aluminum chassis for optimum strength and low compression
        • Proprietary cone material with natural fibers made in-house
        • Soft low damping rubber surround for transient response
        • Non-conducting fiber glass voice coil former for minimum damping
        • Extended copper sleeve on pole piece for low inductance and low distortion
        • Vented coil former
        • CCAW voice coil for reduced moving mass
        • Long life silver lead wires
        • Vented pole piece for reduced compression



        Product details

        SB Acoustics SB17NRX2C35-4 Norex Bass-midwoofer



        The SB17NRX2C35-4 is made with a proprietary cone material that is made in-house, and it has a soft low damping rubber surround for transient response. The voice coil former is made of non-conducting fiberglass, and the pole piece has an extended copper sleeve for low inductance and low distortion. The woofer also has a vented coil former and CCAW voice coil for reduced moving mass. It has a rated power handling of 60 W. The woofer has a vented cast aluminum chassis for optimum strength and low compression and a proprietary cone material with natural fibers made in-house.

        Toon meer

        Specificaties

        Artikelnummer
        SB17NRX2C35-4
        Woofer series
        Bass-midwoofer
        Nominale diameter
        171 mm
        Belastbaarheid (RMS)
        60 Watt
        Belastbaarheid (max)
        120 Watt
        Impedantie (Z)
        4 Ohm
        Gevoeligheid (SPL bij 1m / 2.83V)
        90 dB
        Frequentierespons
        100-3000 Hz
        Spreekspoeldiameter
        35.5 mm
        Gewicht magneet
        0.54 kg
        Gelijkstroomweerstand (Re)
        3.1 Ohm
        Spreekspoelinductie (Le)
        0.13 mH
        Resonantiefrequentie (Fs)
        36 Hz
        Mechanische Q (Qms)
        4.49
        Elektrische Q (Qes)
        0.41
        Totale Q (Qts)
        0.37
        Bewegende massa (Mms)
        13.9 g
        Maximaal verplaatst volume (Vd)
        118 cm2
        Krachtsfactor (BL)
        4.9 Tm
        Equivalentvolume (Vas)
        27.6 liters
        Driver's Mechanical Losses (Rms)
        0.7 kg/s
        Totale buitendiameter
        171 mm
        Totale diepte
        85.9 mm
        # Bevestigingsgaten
        4
        Diameter bevestigingsgaten
        4.3 mm

        Toon meer
