        MW16P-12 Bass-midwoofer

        SB Acoustics MW16P-12 Bass-midwoofer

        €174,95

        6 Op voorraad

        Toevoegen aan winkelwagen

        SB Acoustics MW16P-12 Bass-midwoofer

        0 reviews
        0 van 5
        0 reviews
        5 sterren
        0%
        4 sterren
        0%
        3 sterren
        0%
        2 sterren
        0%
        1 ster
        0%
        Bekijk alle reviews
        Merk: SB Acoustics
        Toon alle Nieuwe producten
        6.5" | 12 Ω
        MW16P-12 Bass-midwoofer
        MW16P-12 Bass-midwoofer
        MW16P-12 Bass-midwoofer
        MW16P-12 Bass-midwoofer
        MW16P-12 Bass-midwoofer
        MW16P-12 Bass-midwoofer
        MW16P-12 Bass-midwoofer
        MW16P-12 Bass-midwoofer
        MW16P-12 Bass-midwoofer
        MW16P-12 Bass-midwoofer
        MW16P-12 Bass-midwoofer
        MW16P-12 Bass-midwoofer
        MW16P-12 Bass-midwoofer
        MW16P-12 Bass-midwoofer
        € 144,59€ 174,95 6 Op voorraad
        • -0% Bestel 4 voor slechts € 174,95 per stuk
        +-
        Toevoegen aan winkelwagen

        Buy now, pay later

        • Gratis verzonden (NL & BE)
        • Nu besteld, dinsdag bezorgd
        • Ten minste twee jaar garantie
        • 45 dagen bedenktijd voor retourneren
        • Klantbeoordeling:
        Zakelijke offerteaanvraag
        Heeft u vragen over dit product?

        Heeft u vragen over dit product?

        Onze klantenservice helpt u graag verder!

        MW16P-12 Bass-midwoofer
        MW16P-12 Bass-midwoofer
        MW16P-12 Bass-midwoofer
        MW16P-12 Bass-midwoofer
        MW16P-12 Bass-midwoofer
        MW16P-12 Bass-midwoofer
        MW16P-12 Bass-midwoofer
        MW16P-12 Bass-midwoofer
        MW16P-12 Bass-midwoofer
        MW16P-12 Bass-midwoofer
        MW16P-12 Bass-midwoofer
        MW16P-12 Bass-midwoofer
        MW16P-12 Bass-midwoofer
        MW16P-12 Bass-midwoofer
        MW16P-12 Bass-midwoofer
        MW16P-12 Bass-midwoofer

        Voor- en nadelen

        Volgens onze specialisten
        • Flexibility thanks to 12 Ohm impedance

        Productomschrijving SB Acoustics MW16P-12 Bass-midwoofer

        The SB Acoustics Satori MW16P-12 is a high-end 6.5" midwoofer designed for discerning audiophiles and speaker builders seeking premium performance. With a focus on low distortion, natural tonal balance, and advanced motor design, this 12-ohm driver is ideal for high-fidelity speaker applications where clarity and precision are paramount.



        Highlights of the SB Acoustics Satori MW16P-12

        • 6.5" Egyptian Papyrus cone for superior damping and natural sound reproduction
        • Vented cast aluminum chassis and neodymium motor system for low distortion
        • Extended copper sleeve on the pole piece to reduce inductance and distortion
        • CCAW voice coil and advanced Bimax spider for improved linearity and transient response



        Product details SB Acoustics Satori MW16P-12

        SB Acoustics Satori MW16P-12 6.5" Midwoofer



        The Satori MW16P-12 by SB Acoustics is part of their flagship line and combines carefully engineered acoustic and mechanical elements to deliver audiophile-grade performance. Featuring a proprietary cone crafted from Egyptian Papyrus™ fibers, the MW16P-12 offers excellent internal damping for a clean and natural midrange. The vented aerodynamic cast aluminum chassis minimizes compression while enhancing structural strength. The powerful low-distortion neodymium motor is optimized with an extended copper sleeve on the pole piece, reducing inductance and minimizing distortion. The non-conductive fiberglass voice coil former, combined with a CCAW (copper-clad aluminum wire) voice coil, results in reduced moving mass and superior transient response. The soft, low-damping rubber surround and advanced Bimax spider further improve linearity and control over cone movement.



        With a free-air resonance (Fs) of 30.6 Hz, sensitivity of 85 dB, and a linear excursion of 12.4 mm (p-p), the MW16P-12 is engineered for accurate low-frequency response and dynamic range. It is ideally suited for high-end 2-way and 3-way designs, particularly in applications that require precise detail and low coloration across the midrange spectrum.

        Toon meer

        Specificaties

        Artikelnummer
        MW16P-12
        EAN
        9501934468238
        Woofer series
        SB Acoustics Satori series
        Woofer type
        Bass-Midwoofer
        Nominale diameter
        6.5"
        Belastbaarheid (RMS)
        50 Watts
        Impedantie (Z)
        12 Ω
        Gevoeligheid (SPL bij 1m / 2.83V)
        85 dB
        Frequentierespons
        35 - 2.000 Hz
        Spreekspoeldiameter
        35.5 mm
        Gelijkstroomweerstand (Re)
        10 Ω
        Spreekspoelinductie (Le)
        0.19 mH
        Resonantiefrequentie (Fs)
        30.6 Hz
        Mechanische Q (Qms)
        4.81
        Elektrische Q (Qes)
        0.40
        Totale Q (Qts)
        0.37
        Bewegende massa (Mms)
        11.5 g
        Compliantie van de ophanging (Cms)
        2.35 mm/N
        Effectief oppervlak (Sd)
        119 cm²
        Krachtsfactor (BL)
        7.4 Tm
        Equivalentvolume (Vas)
        47.3 Liters
        Maximale excursie (Xmax)
        12.4 mm
        Driver's Mechanical Losses (Rms)
        0.46 kg/s
        Surroundmateriaal
        Rubber
        Spreekspoel vormermateriaal
        Fiber glass
        Magneetmateriaal
        Neodymium
        Totale buitendiameter
        165 mm
        Totale diepte
        86.1 mm
        Montagegatdiameter
        140.1 mm
        Bolt Circle Diameter
        153.5 mm
        # Bevestigingsgaten
        6
        Diameter bevestigingsgaten
        4.3 mm

        Toon meer
