    SB Acoustics Satori MR13PNW-8 5" White Egyptian Papyrus Cone Midrange

    € 124,95 2 Op voorraad: levertijd 1 werkdag
    Vented aerodynamic cast aluminum chassis for optimum strength and low compression. Proprietary cone material with EGYPTIAN PAPYRUS™ fibers made in-house with soft low damping rubber surround for optimum transient response.... Toon meer
    Volume voordeel Geniet van deze geweldige kortingsdeals
    • -5% Bestel 4 voor slechts €118,70 per stuk
    • Verzending altijd verzekerd en met track & trace
    • Voor 16u besteld, vandaag verstuurd*
    • Gratis verzending vanaf €99
    • In-house technische support

    Productomschrijving

    Highlights

    • Vented aerodynamic cast aluminum chassis for optimum strength and low compression
    • Proprietary cone material with EGYPTIAN PAPYRUS™ fibres made in-house
    • Soft low damping rubber surround for optimum transient response
    • Advanced BIMAX spider for improved linearity
    • Powerful optimized low distortion neodymium motor system
    • Non-conducting fiber glass voice coil former for minimum damping
    • Extended copper sleeve on pole piece for low inductance and reduced distortion
    • CCAW voice coil for reduced moving mass
    • Long life silver lead wires attached 180° apart for improved stability
    • Vented pole piece and coil former for reduced compression
    • High piston to chassis diameter ratio
    • Gasket and bolt hole protrusions for reduced coupling to speaker cabinet



    Product details

    SB Acoustics Satori MR13PNW-8 5" White Egyptian Papyrus Cone Midrange



    Vented aerodynamic cast aluminum chassis for optimum strength and low compression. Proprietary cone material with EGYPTIAN PAPYRUS™ fibers made in-house with soft low damping rubber surround for optimum transient response. Advanced BIMAX spider for improved linearity. Powerful optimized low distortion neodymium motor system. Non-conducting fiber glass voice coil former for minimum damping. Extended copper sleeve on pole piece for low inductance and reduced distortion. CCAW voice coil for reduced moving mass.



    Long life silver lead wires attached 180° apart for improved stability. Vented pole piece and coil former for reduced compression. High piston to chassis diameter ratio. Gasket and bolt hole protrusions for reduced coupling to speaker cabinet.

    Specificaties

    Artikelnummer
    MR13PNW-8
    Woofer Series
    Satori Series
    Woofer Type
    Midwoofer
    Nominal Diameter
    5"
    Power Handling (RMS)
    30 Watts
    Impedance
    8 ohms
    Sensitivity
    88 dB 2.83V/1m
    Voice Coil Diameter
    1.2"
    DC Resistance (Re)
    6.8 ohms
    Voice Coil Inductance (Le)
    0.11 mH
    Resonant Frequency (Fs)
    47 Hz
    Mechanical Q (Qms)
    4.58
    Electromagnetic Q (Qes)
    0.32
    Total Q (Qts)
    0.30
    Diaphragm Mass Inc. Airload (Mms)
    6.2 g
    Mechanical Compliance of Suspension (Cms)
    1.85 mm/N
    Surface Area of Cone (Sd)
    70 cm2
    BL Product (BL)
    6.2 Tm
    Compliance Equivalent Volume (Vas)
    0.45 ft.³
    Maximum Linear Excursion (Xmax)
    3 mm
