    Peerless by Tymphany NE25VTS-04 1" Silk Dome Tweeter

    € 39,95 Niet op voorraad: binnen 1 week leverbaar
    The Tymphany NE product line of tweeters has leading-edge transducer technology packaged in cutting edge, stylistic designs.... Toon meer
    Volume voordeel Geniet van deze geweldige kortingsdeals
    • -5% Bestel 4 voor slechts €37,95 per stuk
    • Gratis verzending vanaf €99,
    • Voor 16u besteld, vandaag verstuurd*
    • Betaal met IDEAL, PayPal en meer
    • In-house technische support

    Productomschrijving

    The Tymphany NE product line of tweeters has leading-edge transducer technology packaged in cutting edge, stylistic designs.



    Highlights

    • 1" silk dome
    • Advanced design neo motor system
    • Copper caps reduce inductance and extend HF response
    • Aluminum rear chamber lowers resonance and doubles as a heatsink
    • Aluminum face plate and plastic protective grill



    Product details

    Peerless by Tymphany NE25VTS-04 1" Silk Dome Tweeter



    The 25 mm 4 ohm member of the NE family has leading-edge transducer technology packaged in a cutting edge, stylistic design. The tweeters in this family feature finite element analysis designed Neodymium-Iron-Boron magnet (NdFeB) motors, with copper caps for extended frequency response and reduced distortion. The aluminium rear chambers offer extended low frequency performance, while doubling as heat sinking. The butterfly supporting the tweeter diaphragm is made of a high temperature plastic, consistent with the products high temperature performance rating, and features supporting terminals. The dome material in this design is silk, and the design has been optimized for sound quality and clarity. Rounding out the design is an aluminium face plate and plastic grille, which offers protection for the tweeter diaphragm.

    Specificaties

    Artikelnummer
    NE25VTS-04
    Tweeter Type
    Soft Dome
    Tweeter Series
    NE Series
    Cone / Dome Diameter
    1"
    Power Handling (RMS)
    80 Watts
    Impedance
    4 ohms
    Sensitivity
    88.1 dB 1W/1m
    Resonant Frequency (Fs)
    732 Hz
    DC Resistance (Re)
    3.15 ohms
    Voice Coil Inductance (Le)
    0.01 mH
    Mechanical Q (Qms)
    4.41
    Electromagnetic Q (Qes)
    1.12
    Total Q (Qts)
    0.89
    Overall Outside Diameter
    2.59"
    Cutout Diameter
    1.89"
    Depth
    1.22"

    Reviews

    5 from 5Based on 3 reviews
    Schrijf een review
    5 van 5
    Great tweeter, smooth, very musical sound! Very good value endeed!
    Door Radnai L. on 13 Mei 2020
    5 van 5
    I need for replace NE25-VTC-04, CERAMIC , no difference in level, slightly softer and less fragile than the metal dome, highly recommended by a professional stereo store
    Door PHILIPPE R. on 24 Maart 2020
