- Artikelnummer
- SPX-200WP
- Woofer Type
- Full-range
- Nominal Diameter
- 8''
- Power Handling (RMS)
- 50 Watts
- Power Handling (max)
- 100 Watts
- Impedance
- 8 Ohms
- Sensitivity
- 89 dB 1W/m
- Frequency Response
- 40-18,000 Hz
- Voice Coil Diameter
- 25 mm
- Magnet Weight
- 564 g
- DC Resistance (Re)
- 7.6 Ohms
- Voice Coil Inductance (Le)
- 0.35 mH
- Mechanical Q (Qms)
- 4.18
- Electromagnetic Q (Qes)
- 0.69
- Total Q (Qts)
- 0.59
- Diaphragm Mass Inc. Airload (Mms)
- 19.7 g
- Mechanical Compliance of Suspension (Cms)
- 0.95 mm/N
- Surface Area of Cone (Sd)
- 213 cm2
- BL Product (BL)
- 6.79 Tm
- Compliance Equivalent Volume (Vas)
- 60.5 l
- Maximum Linear Excursion (Xmax)
- 2 mm
- Cone / Diaphragm Material
- Polypropylene
- Surround Material
- Rubber
- Voice Coil Wire Material
- Copper
- Voice Coil Former
- Kapton
- Basket / Frame Material
- Stamped steel
- Magnet Material
- Ferrite
- Overall Outside Diameter
- 203 mm
- Overall Depth
- 89 mm
- Baffle Cutout Diameter
- 180 mm
- # Mounting Holes
- 4
- Mounting Hole Diameter
- 5 x 7 mm
