    Monacor SPH-200KE 8" Kevlar Cone Midwoofer 8 Ohm

    € 84,95 Niet op voorraad: binnen 3 werkdagen leverbaar
    Extremely versatile and capable woofer with modern looks thanks to the low-resonance kevlar cone.... Toon meer
    Volume voordeel Geniet van deze geweldige kortingsdeals
    • -5% Bestel 4 voor slechts €80,70 per stuk
    • Gratis verzending vanaf €99,
    • Voor 16u besteld, vandaag verstuurd*
    • Betaal met IDEAL, PayPal en meer
    • In-house technische support

    Productomschrijving

    Extremely versatile and capable woofer with modern looks thanks to the low-resonance kevlar cone.



    Highlights

    • Kevlar cone
    • Very linear response
    • Ideal T/S parameters for vented enclosures



    Product details

    Monacor SPH-200KE 8" Kevlar Cone Midwoofer 8 Ohm



    The Monacor SPH-200KE is a classic Hi-fi midwoofer with modern engineering and looks. The high-quality kevlar cone is one of the main reason for the linear response with relatively little cone-breakup. This allows you to use the SPH-200KE in larger two-way speakers with a competent tweeter but also in multi-way speakers designed to your preferences. The T/S parameters are tailored towards bass-reflex designs, meaning that deep bass reproduction is possible from vented and transmission line enclosures.

    Specificaties

    Artikelnummer
    SPH-200KE
    Woofer Type
    Woofer
    Nominal Diameter
    8''
    Power Handling (RMS)
    80 Watts
    Power Handling (max)
    120 Watts
    Impedance
    8 Ohms
    Sensitivity
    90 dB 1W/m
    Frequency Response
    28-3,000 Hz
    Voice Coil Diameter
    50 mm
    Magnet Weight
    840 g + 50 g
    DC Resistance (Re)
    6.2 Ohms
    Voice Coil Inductance (Le)
    0.75 mH
    Resonant Frequency (Fs)
    28 Hz
    Mechanical Q (Qms)
    4.65
    Electromagnetic Q (Qes)
    0.41
    Total Q (Qts)
    0.38
    Diaphragm Mass Inc. Airload (Mms)
    37 g
    Mechanical Compliance of Suspension (Cms)
    0.89 mm/N
    Surface Area of Cone (Sd)
    207 cm2
    BL Product (BL)
    9.90 Tm
    Compliance Equivalent Volume (Vas)
    54 l
    Maximum Linear Excursion (Xmax)
    4.75 mm
    Cone / Diaphragm Material
    Kevlar
    Surround Material
    Rubber
    Voice Coil Wire Material
    Copper
    Voice Coil Former
    Kapton
    Basket / Frame Material
    Aluminum
    Magnet Material
    Ferrite
    Overall Outside Diameter
    212 mm
    Overall Depth
    100 mm
    Baffle Cutout Diameter
    182 mm
    # Mounting Holes
    4
    Mounting Hole Diameter
    5.5mm
