    Markaudio PLUVIA-7PHD Full-range Woofer

    € 43,35€ 52,45 >10 Op voorraad: Levertijd: 1 werkdag
    Volume voordeel Geniet van deze geweldige kortingsdeals
    • -5% Bestel 4 voor slechts €49,83 per stuk
    • Verzending altijd verzekerd en met track & trace
    • Voor 16u besteld, vandaag verstuurd*
    • Gratis verzending vanaf €99
    • In-house technische support

    Productomschrijving

    The new paper-cone Pluvia 7 PHD was developed with the attractive paper cone, unique suspension and low-mass coil which is wound in high-purity rectangular section copper. The Thiele / Small characteristics are engineered to allow surprising bass performance from a compact drive unit.



    Highlights

    • Latest-model
    • Blue 4’’ natural uncoated paper cone
    • Wide operating range –rolled off high frequencies for vintage tone
    • Low cone profile –very broad directivity pattern
    • Advanced low-distortion motor design
    • Long-stroke suspension with excursion arrestor and progressive-rate spider
    • Low-profile surface-mount reinforced polymer basket



    Product details

    Markaudio Pluvia 7 PHD Full-range Woofer



    The new paper-cone Pluvia seven PHD was developed due to requests from the DIY audio community for a return of paper cone drivers to the latest Markaudio drivers. Its response balance was carefully engineered to provide a shelved down treble and emphasized upper midrange output to address specific requests.



    The attractive paper cone, suspension, and low-mass coil, wound in high-purity rectangular section copper are unique to this model, and the Thiele / Small characteristics engineered to allow surprising bass performance from a compact drive unit. The frame is the familiar, high-quality Pluvia design, which may be conveniently surface or flush-mounted, and has a very open design, allowing good air-flow to the rear of the cone.



    The sound balance is warm, with emphasized upper midrange, and soft treble. Jazz followers in Asia played a role in the final tuning of this driver. Those enthusiasts into vintage and mono recordings using warm tube (valve) amplification may have a particular interest in this driver.

    Specificaties

    Artikelnummer
    PLUVIA-7PHD
    Woofer series
    Pluvia series
    Woofer type
    Full-Range Woofer
    Nominale diameter
    4''
    Belastbaarheid (RMS)
    15 Watts
    Impedantie (Z)
    8 Ohms
    Gevoeligheid
    87 dB 1W/m
    Frequentierespons
    60-30,000 Hz
    Gelijkstroomweerstand (Re)
    3.5 Ohms
    Spreekspoelinductie (Le)
    0.0274 mH
    Resonantiefrequentie (Fs)
    77.79 Hz
    Mechanische Q (Qms)
    2.7968
    Elektrische Q (Qes)
    0.6623
    Totale Q (Qts)
    0.5355
    Bewegende massa (Mms)
    3.2888 g
    Compliantie van de ophanging (Cms)
    1.2728 mm/N
    Effectief oppervlak (Sd)
    50 cm²
    Krachtsfactor (BL)
    2.9146
    Equivalentvolume (Vas)
    4.4905
    Maximale excursie (Xmax)
    4 mm (mechanical)
    Cone / Diaphragm Material
    Uncoated paper
    Surroundmateriaal
    Rubber
    Mand- /framemateriaal
    Cast aluminum
    Magneetmateriaal
    Ferrite
    Totale buitendiameter
    122 mm
    Montagegatdiameter
    100 mm
    Bolt Circle Diameter
    112 mm
    # Bevestigingsgaten
    5
    Diameter bevestigingsgaten
    3.1 mm

    Reviews

    5 from 5Based on 1 reviews
    Schrijf een review
    5 van 5
    Gut, sehr gut.
    Door Alfredo A. on 6 Augustus 2020
