        CHR-90 Champagne Full Range Magnesium Woofer

        CHR-90 Champagne Full Range Magnesium Woofer

        €69,95

        Markaudio CHR-90 Champagne Full Range Magnesium Woofer

        0 reviews
        0 van 5
        0 reviews
        5 sterren
        0%
        4 sterren
        0%
        3 sterren
        0%
        2 sterren
        0%
        1 ster
        0%
        Bekijk alle reviews
        Merk: Markaudio
        € 57,81€ 69,95 10+ Op voorraad
        • -5% Bestel 4 voor slechts € 66,45 per stuk

        Buy now, pay later

        • Gratis verzending vanaf € 99
        • Nu besteld, morgen verstuurd
        • Ten minste twee jaar garantie
        • 45 dagen bedenktijd voor retourneren
        • Klantbeoordeling:
        Zakelijke offerteaanvraag
        Heeft u vragen over dit product?

        Heeft u vragen over dit product?

        Onze klantenservice helpt u graag verder!

        Productomschrijving

        The CHR-90 is an affordable all-new Full-Range 3.5-inch multi-purpose driver unit suitable for use in variety of medium size loudspeakers applications, or as part of a multiway system.



        Highlights

        • Full range drive unit
        • Wide perating range to 20KHz –very linear response
        • Metal cone



        Product Details

        Markaudio CHR-90 Champagne Full Range Magnesium Woofer


        The central mid-range is benign, near flat response, from 1KHz to 6KHz giving end-users and custom builders the potential to use the CHR90 as a mid-field driver in larger multiway applications, useful for balancing out larger radiated surface outputs from big bass units.



        The CHR90 also has potential for use in 2 way applications as a bass-mid driver. Most Markaudio drivers have a purpose designed frequency lift in the lower ranges (typically 100Hz to 500Hz) to compensate for baffle step losses.



        The CHR90 is useful to these applications where end-users and loudspeaker makers need a wider choice on frequency cross-over point selection.



        The CHR90 chassis is an all-new design, dedicated to this driver. All moving parts (powertrain) are new and custom made for this driver. Much work has been done to make the CHR90 a versatile driver and extend the well-known performance characteristics of Markaudio’s products.

        Toon meer

        Specificaties

        Artikelnummer
        CHR-90 Champ
        Woofer series
        CHR
        Woofer type
        Full-Range Driver
        Nominale diameter
        3.5"
        Belastbaarheid (RMS)
        40W
        Impedantie (Z)
        8ohm
        Gevoeligheid (SPL bij 1m / 2.83V)
        89.36 dB
        Frequentierespons
        37Hz to 28KHz rated at +86dB
        Spreekspoelinductie (Le)
        0.0912 mH
        Resonantiefrequentie (Fs)
        44.3 Hz
        Mechanische Q (Qms)
        2.4647
        Elektrische Q (Qes)
        0.4212
        Totale Q (Qts)
        0.36
        Bewegende massa (Mms)
        4.9661 g
        Moving Mass Of Diaphragm (Mmd)
        4.5230 g
        Compliantie van de ophanging (Cms)
        2.5942 mm/N
        Effectief oppervlak (Sd)
        0.0085 m²
        Krachtsfactor (BL)
        4.7260
        Equivalentvolume (Vas)
        26.1403 Ltr
        Maximale excursie (Xmax)
        7 mm

        Toon meer
