    Markaudio CHP-70 Khaki 4" Full Range Paper Woofer Natural

    € 44,95 >10 Op voorraad: Levertijd: 1 werkdag
    The MarkAudio CHP-70 driver is designed to make a semi-vintage classic sound similar to the smaller full-range driver designs from the 1950ʼs.... Toon meer
    Volume voordeel Geniet van deze geweldige kortingsdeals
    • -5% Bestel 4 voor slechts €42,70 per stuk
    • Verzending altijd verzekerd en met track & trace
    • Voor 16u besteld, vandaag verstuurd*
    • Gratis verzending vanaf €99
    • In-house technische support

    Productomschrijving

    The MarkAudio CHP-70 driver is designed to make a semi-vintage classic sound similar to the smaller full range driver designs from the 1950ʼs. Its middle-high range output has been made to "roll-off" from 7-kHz up.



    Highlights

    • Synthetic rubber surround
    • Nomex spider
    • Improved voice coil former



    Product details

    Markaudio CHP-70 Khaki 4" Full Range Paper Woofer Natural



    This updated (Gen. 2) CHP-70 driver is designed to make a semi-vintage classic sound similar to the smaller full-range driver designs from the 1950ʼs. Its middle-high range output has been made to "roll-off" from 7-kHz up. This helps to keep the high range sounding smooth and warm. This driver makes the singer's voice sound very natural, a little warm, pleasing for many hours of listening.



    The CHP-70 Gen. 2 will assist in the control of sharp or hard sounding compressed music (digital). This CHP delivers a tone that appeals to classic music enthusiasts using smaller amplifiers. The off-axis and sound-spread of the CHP-70 are excellent. This driver can fill a room environment with an "easy listening" experience, especially for the human voice. The bass response from the CHP-70 Gen. 2 in a properly tuned box is excellent for this smaller sized driver. Typically, in a Bass-Reflex or Vented box, lower responses close to 40Hz can be obtained.



    Several technical improvements have been done, such as 1 - Improved stiffer frame. 2 - New cap design with the new improved fitting method. 3 - New Japanese designed coil. 4 - New spider for improved bass. The CHP-70 Gen. 2 is an excellent "classic" and "natural" sound driver. The CHP-70 Excursion Arrestor will make a sound when exceeding the driver’s excursion limits.

    Specificaties

    Artikelnummer
    CHP-70 Khaki
    Woofer Series
    CH Series
    Woofer Type
    Full-range
    Nominal Diameter
    4"
    Power Handling (RMS)
    20 Watts
    Impedance
    8 ohms
    Sensitivity
    86.5 dB 2.83V/1m
    Voice Coil Diameter
    0.78"
    DC Resistance (Re)
    7.2 ohms
    Resonant Frequency (Fs)
    50.2 Hz
    Mechanical Q (Qms)
    2.3
    Electromagnetic Q (Qes)
    0.76
    Total Q (Qts)
    0.52
    Diaphragm Mass Inc. Airload (Mms)
    3.7g
    Mechanical Compliance of Suspension (Cms)
    1.31 mm/N
    Surface Area of Cone (Sd)
    50.2 cm²
    BL Product (BL)
    4.2 Tm
    Compliance Equivalent Volume (Vas)
    0.16 ft.³
    Maximum Linear Excursion (Xmax)
    4 mm
    Cone / Diaphragm Material
    Paper
    Overall Outside Diameter
    4.88"
    Overall Depth
    2.2"
    Baffle Cutout Diameter
    4.41"
    # Mounting Holes
    4
