Markaudio CHN-110 Silver 6,75" Full Range Woofer

Momenteel niet voorradig, binnen 4-6 weken leverbaar

  • Artikelcode: CHN-110
  • Niet op voorraad

The CHN-110 is a brand-new 5.75" (actual frame diameter 6.75") driver high fidelity multi-purpose design. Exploiting technologies and features from Markaudio’s continuous research, it has been carefully optimised to provide exceptional bass extension beyo

59,95 € 50,96 Incl. 21% btw

  • Bestel 4 voor €56,95 per stuk en bespaar 5% Sale 5%

Zet op verlanglijst

  • Voor 16u besteld, morgen bezorgd Tooltip Op werkdagen voor 16:00 besteld - en voorradig - morgen geleverd (overmorgen in België)
  • Gratis verzending vanaf € 99,-
  • Betaal gemakkelijk en veilig
  • 45 dagen bedenktijd

Productomschrijving

Markaudio CHN-110 Silver 6,75" Full Range Woofer

The CHN-110 is a brand-new 5.75" (actual frame diameter 6.75") driver high fidelity multi-purpose design. Exploiting technologies and features from Markaudio’s continuous research, it has been carefully optimised to provide exceptional bass extension beyond what many 5 ½ inch to 6 ½ inch mid-bass units can deliver combined with full-range frequency output.



Highlights

  • New low-distortion motor
  • Exceptional bass extension
  • Improved voice coil former



Product Details

Markaudio CHN-110 Silver 6,75" Full Range Woofer



The CHN-110 is a brand-new 5.75" (actual frame diameter 6.75") driver high fidelity multi-purpose design. Exploiting technologies and features from Markaudio’s continuous research, it has been carefully optimised to provide exceptional bass extension beyond what many 5 ½ inch to 6 ½ inch mid-bass units can deliver combined with full-range frequency output. The CHN-110 cone exploits a high-strength series aerospace grade alloy designed to cope with high bending stress loads. Based upon the shallow, wide-dispersion multiform cone concept, the material thickness has been increased to allow greater operational low frequency load capacity. The all-new long-stroke suspension has been optimised to enhance and support the remarkable low-frequency load capacity, and has an air volume compliance of almost 25 litres. With a new low-distortion motor designed to provide a medium Q, the CHN-110 is intended for use in larger enclosures where it can produce significant bass extension for a driver of its size, while providing a sensitivity of over 88dB 1m/w, and a smooth high frequency range extending to 25KHz at +80dB. Other features include an “easy install” heavy duty steel frame for both surface and recessed mounting.



The CHN-110 provides custom builders with wide operational flexibility at an affordable price, allowing use either as a genuine, high-performance full-range driver, or as a wide-range mid-bass with simple filtering. Ideal for use in high-fidelity, home-theatre, commercial A/V applications, and suiting a wide range of enclosure types, it continues Markaudio’s reputation for providing qualitative excellence and advanced mechanical engineering at an accessible level.

Specificaties

Specificaties voor: CHN-110 Silver 6,75" Full Range Woofer

  • Woofer Series Specifieke woofer productlijn van de fabfrikant. CH Series
  • Woofer Type Het type driver bijvoorbeeld subwoofer, mid-woofer, full range of coaxiale woofer. Full-range
  • Nominal Diameter Geschatte diameter van de driver in inch gemeten.
  • Power Handling (RMS) De belasting in elektrisch vermogen uitgedrukt in watt dat een luidsprekerspoel kan opnemen voor een langere tijd, zonder de luidsprekerspoel te beschadigen. RMS staat voor Root Mean Square.
  • Power Handling (max) De maximale belasting in elektrisch vermogen uitgedrukt in watt dat een luidsprekerspoel voor een zeer korte tijd kan opnemen zonder de luidspreker te beschadigen of het geluidskwaliteit niet hoorbaar beïnvloedt. 45watts Nom
  • Bekijk alle specificaties
  • Continuous Program Power
  • Impedance 8 ohms
  • Sensitivity
  • Frequency Response
  • Voice Coil Diameter
  • Magnet Weight
  • DC Resistance (Re)
  • Voice Coil Inductance (Le)
  • Resonant Frequency (Fs)
  • Mechanical Q (Qms) 2.86
  • Electromagnetic Q (Qes) 0.4884
  • Total Q (Qts) 0.4172
  • Diaphragm Mass Inc. Airload (Mms) 8.7700 g
  • Moving Mass Of Diaphragm (Mmd) 8.1228 g
  • Mechanical Compliance of Suspension (Cms) 1.4811
  • Surface Area of Cone (Sd) 0.0109 m2
  • Volume of Displacement (Vd)
  • BL Product (BL) 5.8206 TM
  • Compliance Equivalent Volume (Vas) 24.7335 L
  • Maximum Linear Excursion (Xmax) 8mm 1 way
  • Driver's Mechanical Losses (Rms)
  • Cone / Diaphragm Material Aluminium
  • Surround Material
  • Voice Coil Wire Material
  • Voice Coil Former
  • Dual Voice Coil
  • Basket / Frame Material
  • Magnet Material
  • Shielded
  • Overall Outside Diameter
  • Overall Depth
  • Baffle Cutout Diameter
  • Bolt Circle Diameter
  • # Mounting Holes
  • Mounting Hole Diameter
  • Sealed Volume
  • Sealed F3
  • Vented Volume
  • Vented F3
