        PT6825-8 8" Planar Mid/Tweeter 8 Ohm

        PT6825-8 8" Planar Mid/Tweeter 8 Ohm

        €89,95

        GRS PT6825-8 8" Planar Mid/Tweeter 8 Ohm

        5 reviews
        5 van 5
        5 reviews
        5 sterren
        100%
        4 sterren
        0%
        3 sterren
        0%
        2 sterren
        0%
        1 ster
        0%
        Bekijk alle reviews
        Merk: GRS
        € 74,34€ 89,95 10+ Op voorraad
        • -5% Bestel 4 voor slechts € 85,45 per stuk

        Buy now, pay later

        • Gratis verzending vanaf € 99
        • Nu besteld, morgen bezorgd
        • Ten minste twee jaar garantie
        • 45 dagen bedenktijd voor retourneren
        • Klantbeoordeling:
        Zakelijke offerteaanvraag
        Heeft u vragen over dit product?

        Heeft u vragen over dit product?

        Onze klantenservice helpt u graag verder!

        Productomschrijving

        Capable of delivering extremely wide bandwidth with low distortion, the GRS PT6825-8 open back planar driver is designed to deliver natural midrange response while remaining accurate to the highest frequencies. With an extremely lightweight diaphragm and a neodymium motor system, this driver is capable of excellent transient response with amazing dynamics. The open back construction produces true dipole radiation which is ideal for use in open baffle designs.



        Highlights

        • Extremely low mass diaphragm provides excellent transient response and accuracy
        • Large diaphragm produces high efficiency with incredible dynamics
        • Remarkably wide bandwidth for controlled transition to woofer and tweeter drivers
        • Open back delivers true dipole radiation for use in open baffle designs
        • Linear impedance simplifies crossover design
        • Shallow mounting depth for use in low profile designs



        Product Details

        GRS PT6825-8 8" Planar Mid/Tweeter 8 Ohm



        With the ability to provide low distortion output from 500-20,000 Hz, the GRS PT6828-8 open back midrange/tweeter is an excellent choice for use in 2-way designs or even as a drop in replacement in many existing systems. Thanks to a lightweight damped polyimide diaphragm driven by 30 powerful neodymium magnets in a push-pull arrangement, this driver is capable of incredible transient response and detail. With a nearly linear 6.4 ohm impedance keeps crossover design simple with predictable final results. In addition, the open back design gives this midrange/tweeter true dipole radiation making it the perfect choice for use in high end open baffle speaker designs.

        Toon meer

        Specificaties

        Artikelnummer
        PT6825-8
        Tweeter type
        Planar
        Belastbaarheid (RMS)
        35 Watts
        Impedantie (Z)
        8 Ω
        Gevoeligheid (SPL bij 1m / 2.83V)
        92 dB
        Frequentierespons
        250 to 20,000 Hz
        Gelijstroomweerstand (Re)
        6.4 ohms
        Voice Coil Inductance (Le)
        0.02 mH
        Totale Q (Qts)
        2.06
        Totale buitendiameter
        7.87" x 3.5"
        Montagegatdiameter
        6.89" x 2.61"
        Diepte
        0.37"

        Toon meer

        5 van 5
        my new product power and loving it
        Door zulkifly on 30 Januari 2024
        5 van 5
        Dit is een uitstekende tweeter. Ik gebruik ze in een dipool luidspreker.
        Door Marinus on 18 Juni 2023
