        PT6816-8 8" Planar Slim Tweeter 8 Ohm

        PT6816-8 8" Planar Slim Tweeter 8 Ohm

        €69,95

        GRS PT6816-8 8" Planar Slim Tweeter 8 Ohm

        4 reviews
        5 van 5
        4 reviews
        5 sterren
        75%
        4 sterren
        25%
        3 sterren
        0%
        2 sterren
        0%
        1 ster
        0%
        Bekijk alle reviews
        Merk: GRS
        € 57,81€ 69,95 10+ Op voorraad
        • -5% Bestel 4 voor slechts € 66,45 per stuk

        Buy now, pay later

        • Gratis verzending vanaf € 99
        • Nu besteld, morgen verstuurd
        • Ten minste twee jaar garantie
        • 45 dagen bedenktijd voor retourneren
        • Klantbeoordeling:
        Zakelijke offerteaanvraag
        Heeft u vragen over dit product?

        Heeft u vragen over dit product?

        Onze klantenservice helpt u graag verder!

        Productomschrijving

        Capable of delivering wide bandwidth with low distortion, the GRS PT6816-8 open back planar driver has the ability to perform well from upper midrange to the highest frequencies. With an extremely lightweight diaphragm and a neodymium motor system, this driver is capable of excellent transient response with amazing dynamics. The open back construction produces true dipole radiation which is ideal for use in open baffle designs. With a narrow footprint and minimal flange, the PT6816-8 is also ideal for line array use.



        Highlights

        • Extremely low mass diaphragm provides excellent transient response and accuracy
        • Narrow design to deliver excellent off axis consistency
        • Multiple neodymium magnets in push pull arrangement for incredible control and low distortion
        • Open back delivers true dipole radiation making this driver ideal for open baffle line array designs
        • Linear impedance simplifies crossover design
        • Shallow mounting depth for use in low profile designs



        Product Details

        GRS PT6816-8 8" Planar Slim Tweeter 8 Ohm



        The GRS PT6816-8 open back planar midrange/tweeter is designed to deliver low distortion with dynamic response. Thanks to a lightweight damped polyimide diaphragm that is driven by 18 powerful neodymium magnets in a push-pull arrangement, this driver is capable of incredible transient response and wide bandwidth. The almost linear 6.4 ohm impedance makes crossover design simple and minimizes the number of components required to achieve your required roll off. In addition, the open back design gives this tweeter true dipole radiation making it the perfect choice for use in open baffle speaker designs. With wide dispersion capabilities and minimal mounting flange, the PT6816-8 is an excellent choice for use in high output line arrays.

        Toon meer

        Specificaties

        Artikelnummer
        PT6816-8
        Tweeter type
        Planar
        Belastbaarheid (RMS)
        30 Watts
        Impedantie (Z)
        8 Ω
        Gevoeligheid (SPL bij 1m / 2.83V)
        94 dB
        Frequentierespons
        320 to 20,000 Hz
        Gelijstroomweerstand (Re)
        6.4 ohms
        Voice Coil Inductance (Le)
        0.02 mH
        Mechanische Q (Qms)
        6.19
        Totale Q (Qts)
        4.57
        Totale buitendiameter
        7.875" x 2.56"
        Montagegatdiameter
        6.89" x 1.65"
        Diepte
        0.47"

        Toon meer

        5 van 5
        Looks nice.
        Door Tomas on 23 April 2024
        4 van 5
        AMT: Sehr guter klang. Höhen etwas zu scharf trotz korrektur
        Door Rainer on 27 Maart 2023
