        Productomschrijving FaitalPRO 5HX140-8F Bass-midwoofer Coaxial

        Compact coaxial 5" speaker with integrated compression driver and 8-ohm impedance, engineered for precise imaging and full-range performance in professional and space-limited audio systems.



        Highlights of the FaitalPRO 5HX140-8F Bass-midwoofer Coaxial

        • 5" (130mm) bass-midwoofer with integrated 1" compression driver for true coaxial performance
        • 8-ohm impedance for flexible system integration and amplifier compatibility
        • Coherent point-source design for precise imaging and time alignment
        • Extended frequency range and high output in compact enclosure designs



        Product details FaitalPRO 5HX140-8F Bass-midwoofer Coaxial

        FaitalPRO 5HX140-8F Bass-midwoofer Coaxial Full-range Coaxial Driver Unit



        The FaitalPRO 5HX140-8F is a professional coaxial loudspeaker designed to deliver phase-accurate, full-range sound in a compact footprint. It features a 5" bass-midrange driver paired with an integrated 1" compression driver mounted coaxially, allowing for precise time alignment and superior off-axis consistency. With an 8-ohm impedance, it is easily integrated into a wide range of amplifier and crossover setups. The driver delivers strong low-mid performance with clean, extended highs, making it ideal for portable PA systems, monitors, and compact high-fidelity enclosures. The high-efficiency ferrite motor system ensures excellent output and control, while the coaxial configuration delivers a true point-source audio experience, essential for accurate imaging and natural vocal reproduction. Rugged construction and performance tuning make the 5HX140-8P a top choice for professional installs and custom loudspeaker designs.

        Toon meer

        Specificaties

        Artikelnummer
        5HX140-8F
        EAN
        9509367684188
        Woofer type
        Bass-Midwoofer
        Nominale diameter
        5''
        Belastbaarheid (RMS)
        120 Watts
        Belastbaarheid (max)
        240 Watts (LF) + 30 Watts (HF)
        Impedantie (Z)
        8 Ω
        Gevoeligheid (SPL bij 1m / 2.83V)
        91 dB (LF) + 101 dB (HF)
        Frequentierespons
        100-8.000 Hz (LF) + 1.500-18.000 Hz (HF)
        Spreekspoeldiameter
        37 mm (LF) + 25 mm (HF)
        Gelijkstroomweerstand (Re)
        5.9 Ω
        Spreekspoelinductie (Le)
        0.29 mH
        Resonantiefrequentie (Fs)
        100 Hz
        Mechanische Q (Qms)
        4.8
        Elektrische Q (Qes)
        0.45
        Totale Q (Qts)
        0.41
        Bewegende massa (Mms)
        7.5 g
        Moving Mass Of Diaphragm (Mmd)
        6.6 g
        Compliantie van de ophanging (Cms)
        0.34 mm/N
        Effectief oppervlak (Sd)
        85 cm²
        Krachtsfactor (BL)
        8 N/A
        Equivalentvolume (Vas)
        3.4 dm³
        Maximale excursie (Xmax)
        5.10 mm
        Driver's Mechanical Losses (Rms)
        1.0 kg/s
        Spreekspoel draadmateriaal
        Aluminium
        Spreekspoel vormermateriaal
        Kapton
        Mand- /framemateriaal
        Aluminium
        Magneetmateriaal
        Neodymium
        Totale buitendiameter
        150 mm
        Totale diepte
        74 mm
        Montagegatdiameter
        118 mm
        Bolt Circle Diameter
        139 mm
        # Bevestigingsgaten
        4
        Diameter bevestigingsgaten
        5.3 mm
