        5FE120-4F 5" Bass-midwoofer 4 Ohm

        FaitalPRO 5FE120-4F 5" Bass-midwoofer 4 Ohm

        €39,95

        1 Op voorraad

        Toevoegen aan winkelwagen

        FaitalPRO 5FE120-4F 5" Bass-midwoofer 4 Ohm

        1 klantbeoordelingen
        5 van 5
        1 klantbeoordelingen
        5 sterren
        100%
        4 sterren
        0%
        3 sterren
        0%
        2 sterren
        0%
        1 ster
        0%
        Bekijk alle reviews
        Merk: FaitalPRO
        Toon alle Bass-mid woofer
        5" | 4 Ω
        5FE120-4F 5" Bass-midwoofer 4 Ohm
        5FE120-4F 5" Bass-midwoofer 4 Ohm
        5FE120-4F 5" Bass-midwoofer 4 Ohm
        5FE120-4F 5" Bass-midwoofer 4 Ohm
        5FE120-4F 5" Bass-midwoofer 4 Ohm
        5FE120-4F 5" Bass-midwoofer 4 Ohm
        € 33,02€ 39,95 1 Op voorraad
        • -5% Bestel 4 voor slechts € 37,95 per stuk
        +-
        Toevoegen aan winkelwagen

        Buy now, pay later

        • Gratis verzending vanaf € 99
        • Voor 16u besteld, vandaag verstuurd
        • Ten minste twee jaar garantie
        • 45 dagen bedenktijd voor retourneren
        • Klantbeoordeling:
        Zakelijke offerteaanvraag
        Heeft u vragen over dit product?

        Heeft u vragen over dit product?

        Onze klantenservice helpt u graag verder!

        5FE120-4F 5" Bass-midwoofer 4 Ohm
        5FE120-4F 5" Bass-midwoofer 4 Ohm
        5FE120-4F 5" Bass-midwoofer 4 Ohm
        5FE120-4F 5" Bass-midwoofer 4 Ohm
        5FE120-4F 5" Bass-midwoofer 4 Ohm
        5FE120-4F 5" Bass-midwoofer 4 Ohm

        Productomschrijving FaitalPRO 5FE120-4F Bass-midwoofer

        Advanced 5" bass-midwoofer with 4-ohm impedance and high power handling, engineered for tight low-end and articulate midrange in compact, professional-grade audio systems.



        Highlights of the FaitalPRO 5FE120-4F Bass-midwoofer

        • 5" (130mm) bass-midrange driver with 4-ohm impedance for efficient low-voltage applications
        • High sensitivity of 91dB (1W/1m) and robust output in small enclosures
        • Optimized motor with ferrite magnet for strong flux and reduced distortion
        • Wide frequency range from approximately 70Hz to 6.5kHz supports two-way speaker designs



        Product details FaitalPRO 5FE120-4F Bass-midwoofer

        FaitalPRO 5FE120-4F Bass-midwoofer Bass-Midrange Driver Unit



        The FaitalPRO 5FE120-4F is a compact yet powerful bass-midwoofer built for high-performance audio systems where size, clarity, and punch are critical. With its 4-ohm impedance, this driver excels in low-voltage systems or parallel configurations. It features a precision-engineered ferrite magnet and treated paper cone, resulting in low distortion and controlled excursion. Delivering a frequency response from around 70Hz to 6.5kHz, the 5FE120-4F is ideal for compact two-way loudspeakers, portable PA setups, or studio monitors. Its steel basket and efficient cooling design support stable operation even at higher volumes. With a sensitivity of 91dB, this model delivers articulate midrange and tight bass with excellent efficiency—making it a trusted component for sound professionals and audio system designers alike.

        Toon meer

        Specificaties

        Artikelnummer
        5FE120-4F
        EAN
        9509819264296
        Woofer type
        Bass-Midwoofer
        Nominale diameter
        5''
        Belastbaarheid (RMS)
        80 Watts
        Belastbaarheid (max)
        160 Watts
        Impedantie (Z)
        4 Ω
        Gevoeligheid (SPL bij 1m / 2.83V)
        88 dB
        Frequentierespons
        63 - 6.300 Hz
        Spreekspoeldiameter
        32 mm
        Gelijkstroomweerstand (Re)
        3.1 Ω
        Spreekspoelinductie (Le)
        0.33 mH
        Resonantiefrequentie (Fs)
        65 Hz
        Mechanische Q (Qms)
        8.2
        Elektrische Q (Qes)
        0.4
        Totale Q (Qts)
        0.38
        Bewegende massa (Mms)
        10.9 g
        Moving Mass Of Diaphragm (Mmd)
        10.5 g
        Compliantie van de ophanging (Cms)
        0.55 mm/N
        Effectief oppervlak (Sd)
        79.8 cm²
        Krachtsfactor (BL)
        5.9 N/A
        Equivalentvolume (Vas)
        5.0 dm³
        Maximale excursie (Xmax)
        5.2 mm
        Driver's Mechanical Losses (Rms)
        0.55 kg/s
        Spreekspoel draadmateriaal
        Cu
        Spreekspoel vormermateriaal
        Kapton
        Mand- /framemateriaal
        Steel
        Magneetmateriaal
        Ferrite
        Totale buitendiameter
        144.8 mm
        Totale diepte
        71.5 mm
        Montagegatdiameter
        114 mm
        Bolt Circle Diameter
        133 mm
        # Bevestigingsgaten
        4
        Diameter bevestigingsgaten
        5.3 mm

        Toon meer
