        Productomschrijving FaitalPRO 18HP1030-4P Subwoofer

        The FaitalPRO 18HP1030 is a powerful and durable 18-inch subwoofer engineered for deep bass response and consistent high-power performance. Built with a 4" copper voice coil and ferrite magnet system, it’s ideal for use in large-format PA systems, bass reflex cabinets, and high-SPL subwoofer designs.



        Highlights of the FaitalPRO 18HP1030

        • 1200 W AES and 2400 W peak power handling via a 4" copper voice coil
        • High 98 dB sensitivity ensures strong low-frequency output with moderate amplification
        • Ferrite ring magnet and aluminum demodulation ring for low distortion at high excursions
        • Triple-roll surround and deep 12.45 mm Xmax for clean sub-bass reproduction



        Product details FaitalPRO 18HP1030

        FaitalPRO 18HP1030 High-Performance Subwoofer – 4 Ohm Version



        The FaitalPRO 18HP1030 is a rugged 18" woofer designed to deliver tight, powerful low frequencies in professional subwoofer systems. Its 100 mm (4 in) copper voice coil and glass fiber former provide excellent thermal resistance, handling up to 1200 W AES and 2400 W peak power. With 98 dB sensitivity and a frequency response from 35 Hz to 1600 Hz, it delivers controlled bass for demanding live and installation setups.

        Using a ferrite ring magnet and aluminum demodulation ring, the 18HP1030 minimizes distortion and heat buildup during prolonged use. Its triple-roll surround and dual symmetrical spiders enable a generous 12.45 mm Xmax and 23.1 mm mechanical Xdamage for high excursion performance. Ideal for reflex and horn-loaded enclosures, this subwoofer offers a balance of power, reliability, and depth, suited to portable and fixed systems alike.

        Toon meer

        Specificaties

        Artikelnummer
        18HP1030-4P
        EAN
        0848864008073
        Woofer type
        Subwoofer
        Nominale diameter
        18''
        Belastbaarheid (RMS)
        1200 Watts
        Belastbaarheid (max)
        2400 Watts
        Impedantie (Z)
        8 Ω
        Gevoeligheid (SPL bij 1m / 2.83V)
        98 dB
        Frequentierespons
        35 - 1.600 Hz
        Spreekspoeldiameter
        100 mm
        Gelijkstroomweerstand (Re)
        5 Ω
        Spreekspoelinductie (Le)
        1.48 mH
        Resonantiefrequentie (Fs)
        35 Hz
        Mechanische Q (Qms)
        11.6
        Elektrische Q (Qes)
        0.43
        Totale Q (Qts)
        0.41
        Bewegende massa (Mms)
        228.6 g
        Moving Mass Of Diaphragm (Mmd)
        180.9 g
        Compliantie van de ophanging (Cms)
        0.09 mm/N
        Effectief oppervlak (Sd)
        1212 cm²
        Krachtsfactor (BL)
        24.3 N/A
        Equivalentvolume (Vas)
        185.5 cm³
        Maximale excursie (Xmax)
        12.45 mm
        Driver's Mechanical Losses (Rms)
        4.3 kg/s
        Spreekspoel draadmateriaal
        Cu
        Spreekspoel vormermateriaal
        Glass Fiber
        Mand- /framemateriaal
        Aluminium
        Magneetmateriaal
        Ferrite
        Totale buitendiameter
        460 mm
        Totale diepte
        208.5 mm
        Montagegatdiameter
        421 mm
        Bolt Circle Diameter
        440 mm
        # Bevestigingsgaten
        8
        Diameter bevestigingsgaten
        7.4 mm
