        Reference RS180S-8 Bass-midwoofer

        Reference RS180S-8 Bass-midwoofer

        €93,95

        Dayton Audio Reference RS180S-8 Bass-midwoofer

        2 reviews
        5 van 5
        2 reviews
        5 sterren
        50%
        4 sterren
        50%
        3 sterren
        0%
        2 sterren
        0%
        1 ster
        0%
        Bekijk alle reviews
        € 77,64€ 93,95 10+ Op voorraad
        • -5% Bestel 4 voor slechts € 89,25 per stuk

        Buy now, pay later

        • Gratis verzending vanaf € 99
        • Nu besteld, morgen verstuurd
        • Vijf jaar garantie
        • 45 dagen bedenktijd voor retourneren
        • Klantbeoordeling:
        Zakelijke offerteaanvraag
        Heeft u vragen over dit product?

        Heeft u vragen over dit product?

        Onze klantenservice helpt u graag verder!

        Productomschrijving

        The Dayton Audio Reference Series sets a new standard of value in high-performance loudspeaker drivers. Utilizing a low-distortion motor system with two short-circuit paths and a rigid aluminum cone, the Reference Series can outperform drivers that cost several times the price.



        Highlights

        • Long-excursion motor and suspension for strong bass performance
        • Subtle yet high-tech look makes a bold cosmetic statement
        • Ultra-low stray magnetic field allows extremely close proximity to CRT's
        • Designed and engineered in the U.S.A.



        Product details

        Dayton Audio RS180S-8 7" Reference Shielded Woofer 8 Ohm



        The Dayton Audio Reference Series sets a new standard of value in high-performance loudspeaker drivers. Utilizing a low-distortion motor system with two short-circuit paths and a rigid aluminum cone, the Reference Series can outperform drivers that cost several times the price. Their low-distortion characteristics and high excursion capabilities provide exceptional clarity, detail, and dynamics. Woofers feature a shielded motor system, black anodized cone, heavy-duty 6-hole cast frame, low-loss rubber surround, and solid aluminum phase plug.



        Toon meer

        Specificaties

        Artikelnummer
        RS180S-8
        Woofer series
        Reference Series
        Woofer type
        Midwoofer
        Nominale diameter
        7"
        Belastbaarheid (RMS)
        60 watts
        Belastbaarheid (max)
        120 watts
        Impedantie (Z)
        8 ohms
        Gevoeligheid (SPL bij 1m / 2.83V)
        86.9 dB
        Frequentierespons
        41 - 3,600 Hz
        Spreekspoeldiameter
        25 mm
        Gelijkstroomweerstand (Re)
        6.4 ohms
        Spreekspoelinductie (Le)
        0.79 mH @ 1 kHz
        Resonantiefrequentie (Fs)
        37.7 Hz
        Mechanische Q (Qms)
        1.45
        Elektrische Q (Qes)
        0.49
        Totale Q (Qts)
        0.36
        Bewegende massa (Mms)
        17g
        Compliantie van de ophanging (Cms)
        1.05 mm/N
        Effectief oppervlak (Sd)
        124.7 cm²
        Maximaal verplaatst volume (Vd)
        74.8 cm³
        Krachtsfactor (BL)
        7.28 Tm
        Equivalentvolume (Vas)
        23 liters
        Maximale excursie (Xmax)
        6 mm
        Cone / Diaphragm Material
        Black Anodized Aluminum Cone
        Surroundmateriaal
        Rubber
        Spreekspoel draadmateriaal
        Copper
        Spreekspoel vormermateriaal
        Aluminum
        Mand- /framemateriaal
        Cast Aluminum
        Magneetmateriaal
        Ferrite
        Magnetisch afgeschermd
        Yes
        Totale buitendiameter
        180.5 mm
        Totale diepte
        98 mm
        Montagegatdiameter
        146 mm
        # Bevestigingsgaten
        6
        Gesloten volume
        0.17 ft.³
        Gesloten F3
        99 Hz
        Gepoort volume
        0.49 ft.³
        Gepoort F3
        56 Hz

        Toon meer

        5 van 5
        Excellent midrange drivers. Been using them for 6 months (DIY build; ported speakers with these mid/low range drivers and RST28F-4 Dome tweeters. Works like a charm.
        Door Subhasish on 2 Mei 2020
        4 van 5
        Prima product, prima levering!!
        Door bert r. on 15 Oktober 2019
