        Reference RS180-8 Bass-midwoofer

        Reference RS180-8 Bass-midwoofer

        €86,45

        Dayton Audio Reference RS180-8 Bass-midwoofer

        2 reviews
        5 van 5
        2 reviews
        5 sterren
        100%
        4 sterren
        0%
        3 sterren
        0%
        2 sterren
        0%
        1 ster
        0%
        Bekijk alle reviews
        € 71,45€ 86,45 10+ Op voorraad
        • -5% Bestel 4 voor slechts € 82,13 per stuk

        Buy now, pay later

        • Gratis verzending vanaf € 99
        • Nu besteld, morgen bezorgd
        • Vijf jaar garantie
        • 45 dagen bedenktijd voor retourneren
        • Klantbeoordeling:
        Zakelijke offerteaanvraag
        Heeft u vragen over dit product?

        Heeft u vragen over dit product?

        Onze klantenservice helpt u graag verder!

        Productomschrijving

        Dayton Audio Reference Series RS180-8 7" woofers deliver exceptional clarity, detail, and dynamics--and of course, incredibly low distortion.



        Highlights

        • One of the lowest distortion, highest resolution driver series available
        • Low-distortion high-excursion motor system with two short-circuit paths
        • Compliant suspension and rigid black anodized aluminum cone for strong bass performance
        • Heavy-duty 6-hole cast frame, low-loss rubber surround, and solid aluminum phase plug
        • Designed and engineered in the USA



        Product details

        Dayton Audio RS180-8 7" Reference Woofer



        The Dayton Audio Reference Series was conceived with one goal in mind—low distortion. Each speaker was carefully designed and optimized to offer the highest performance with the lowest distortion levels. At the same time, by focusing on features that contribute to sound quality and eliminating unnecessary frills, the drivers offer value unparalleled in the industry. Dayton Audio Reference Series RS180-8 7" woofers deliver exceptional clarity, detail, and dynamics—and of course, incredibly low distortion.

        Toon meer

        Specificaties

        Artikelnummer
        RS180-8
        Woofer series
        Reference Series
        Woofer type
        Midwoofer
        Nominale diameter
        7"
        Belastbaarheid (RMS)
        60 watts
        Belastbaarheid (max)
        120 watts
        Impedantie (Z)
        8 ohms
        Gevoeligheid (SPL bij 1m / 2.83V)
        87.1 dB
        Frequentierespons
        39 - 3,600 Hz
        Spreekspoeldiameter
        38 mm
        Gelijkstroomweerstand (Re)
        6.4 ohms
        Spreekspoelinductie (Le)
        0.73 mH @ 1 kHz
        Resonantiefrequentie (Fs)
        35.7 Hz
        Mechanische Q (Qms)
        1.22
        Elektrische Q (Qes)
        0.42
        Totale Q (Qts)
        0.31
        Bewegende massa (Mms)
        17.9g
        Compliantie van de ophanging (Cms)
        1.12 mm/N
        Effectief oppervlak (Sd)
        124.7 cm²
        Maximaal verplaatst volume (Vd)
        74.8 cm³
        Krachtsfactor (BL)
        7.82 Tm
        Equivalentvolume (Vas)
        24.4 liters
        Maximale excursie (Xmax)
        6 mm
        Cone / Diaphragm Material
        Black Anodized Aluminum Cone
        Surroundmateriaal
        Rubber
        Spreekspoel draadmateriaal
        Copper
        Spreekspoel vormermateriaal
        Aluminum
        Mand- /framemateriaal
        Cast Aluminum
        Magneetmateriaal
        Ferrite
        Totale buitendiameter
        180.5 mm
        Totale diepte
        81 mm
        Montagegatdiameter
        146 mm
        # Bevestigingsgaten
        6
        Gesloten volume
        0.16 ft.³
        Gesloten F3
        98 Hz
        Gepoort volume
        0.43 ft.³
        Gepoort F3
        56 Hz

        Toon meer

        5 van 5
        Habe vor Jahren den Klang und Ton Dayton Spring gebaut und baue jetzt eine überholte Version mit 6 mal RS180-8 und 2 Mitteltöner pro Kanal (D'Appolito). Ich bin sehr begeistert über die Qualität der Dayton Drivers. Sie sind dabei sehr erschwinglich. Kann ich nur empfehlen!
        Door Wiebe Schraa on 9 Augustus 2023
        5 van 5
        Bought this Mid as a Replacement. The Paper Cone Has a very smooth Sound. The Enclosure is Tuned to about 40 hz. Very detailed and punshy Bass and Exelent Vocals. Really Good Overall Value. Delivery was Quick and without and Problems as usual. will definitely Order again.
        Door FND on 20 September 2020
