        CD-314Fe/Ti Compression Driver

        Beyma CD-314Fe/Ti Compression Driver

        €219,95

        4 verwacht op 02-01-2026

        Toevoegen aan winkelwagen

        Beyma CD-314Fe/Ti Compression Driver

        0 reviews
        0 van 5
        0 reviews
        5 sterren
        0%
        4 sterren
        0%
        3 sterren
        0%
        2 sterren
        0%
        1 ster
        0%
        Bekijk alle reviews
        Merk: Beyma
        Toon alle Nieuwe producten
        1.4" | 8 Ω
        CD-314Fe/Ti Compression Driver
        CD-314Fe/Ti Compression Driver
        CD-314Fe/Ti Compression Driver
        CD-314Fe/Ti Compression Driver
        € 181,78€ 219,95 Niet op voorraad4 verwacht op 02-01-2026
        +-
        Toevoegen aan winkelwagen

        Buy now, pay later

        • Gratis verzonden (NL & BE)
        • Snel weer op voorraad
        • Ten minste twee jaar garantie
        • 45 dagen bedenktijd voor retourneren
        • Klantbeoordeling:
        Zakelijke offerteaanvraag
        Heeft u vragen over dit product?

        Heeft u vragen over dit product?

        Onze klantenservice helpt u graag verder!

        CD-314Fe/Ti Compression Driver
        CD-314Fe/Ti Compression Driver
        CD-314Fe/Ti Compression Driver
        CD-314Fe/Ti Compression Driver

        Voor- en nadelen

        Volgens onze specialisten
        • Deplocex® Patent Pending Technology for improved thermal disipation, low power compression losses and high power handling

        Productomschrijving Beyma CD-314Fe/Ti Compression Driver

        The Beyma CD-314Fe is a premium 1.4" exit compression driver designed to deliver powerful, clear, and precise high-frequency performance in demanding professional audio environments. Engineered with a 3-inch copper-clad aluminum voice coil and advanced thermal management, this driver combines power and efficiency in a compact form factor.



        Highlights of the Beyma CD-314Fe

        • 1.4” throat exit with large 3” copper-clad aluminum voice coil on a Nomex former
        • Handles up to 260 W program power above 1.2 kHz with high 109 dB sensitivity
        • FEM-optimized titanium diaphragm for extended response and minimized resonances
        • Features Deplocex® thermal technology and a ceramic magnetic circuit for low compression losses and durability



        Product details Beyma CD-314Fe

        Beyma CD-314Fe Compression Driver



        The Beyma CD-314Fe is a next-generation high-output compression driver built for professional audio systems requiring clarity and reliability at high sound pressure levels. With a 1.4-inch throat and a large 3-inch voice coil wound in copper-clad aluminum on a Nomex former, it offers exceptional thermal performance and power handling. This model delivers 260 W of program power above 1.2 kHz and features a sensitivity of 109 dB (1W/1m), ensuring excellent projection and detail. The titanium dome and surround, optimized through finite element modeling (FEM), offer a linear and extended frequency response from 0.6 to 20 kHz while reducing unwanted resonances. It incorporates a copper shorting cap to minimize harmonic distortion and provide a more linear impedance response. The CD-314Fe is designed around a FEM-optimized ceramic magnetic circuit, providing a balanced combination of weight, magnetic strength, and durability. Its proprietary metal alloy phase plug enhances acoustic performance, and the rugged aluminum cover protects internal components. Physically, the unit measures 165 mm in diameter and 69.6 mm in depth, with mounting via four M6 threaded holes spaced 90º apart on a 101.6 mm circle. At 5.4 kg, it is heavier than neodymium-based alternatives but offers robust performance ideal for touring systems, large-format arrays, or high-end installations demanding both power and fidelity.

        Toon meer

        Specificaties

        Artikelnummer
        CD-314Fe/Ti
        EAN
        8435469051539
        Tweeter type
        Compression Driver
        Belastbaarheid (RMS)
        250 Watts
        Impedantie (Z)
        8 Ω
        Gevoeligheid (SPL bij 1m / 2.83V)
        109 dB
        Totale buitendiameter
        165 mm
        Diepte
        69.6 mm
        Bevestigingstype
        Screws 4 x 6 mm

        Toon meer
