        CD-10Fe/N Compression Driver

        Beyma CD-10Fe/N Compression Driver

        €79,95

        3 verwacht op 02-01-2026

        Toevoegen aan winkelwagen

        Beyma CD-10Fe/N Compression Driver

        0 reviews
        0 van 5
        0 reviews
        5 sterren
        0%
        4 sterren
        0%
        3 sterren
        0%
        2 sterren
        0%
        1 ster
        0%
        Bekijk alle reviews
        Merk: Beyma
        Toon alle Nieuwe producten
        1" | 8 Ω
        CD-10Fe/N Compression Driver
        CD-10Fe/N Compression Driver
        CD-10Fe/N Compression Driver
        CD-10Fe/N Compression Driver
        € 66,07€ 79,95 Niet op voorraad3 verwacht op 02-01-2026
        • -5% Bestel 4 voor slechts € 75,95 per stuk
        +-
        Toevoegen aan winkelwagen

        Buy now, pay later

        • Gratis verzending vanaf € 99
        • Snel weer op voorraad
        • Ten minste twee jaar garantie
        • 45 dagen bedenktijd voor retourneren
        • Klantbeoordeling:
        Zakelijke offerteaanvraag
        Heeft u vragen over dit product?

        Heeft u vragen over dit product?

        Onze klantenservice helpt u graag verder!

        CD-10Fe/N Compression Driver
        CD-10Fe/N Compression Driver
        CD-10Fe/N Compression Driver
        CD-10Fe/N Compression Driver

        Voor- en nadelen

        Volgens onze specialisten
        • Ultra lightweight edgewound aluminium ribbon voice coil

        Productomschrijving Beyma CD-10Fe/N Compression Driver

        The Beyma CD-10Fe/N is a compact and efficient 1” compression driver engineered for natural sound reproduction and high output. Designed with a PM-4 polymer diaphragm, lightweight aluminum ribbon voice coil, and a robust ferrite magnet, it offers excellent performance in a lightweight and versatile package.



        Highlights of the Beyma CD-10Fe/N

        • 1” throat exit with ultra-lightweight 1.75” aluminum ribbon voice coil
        • Delivers 140 W program power above 1.2 kHz with 109 dB sensitivity
        • PM-4 polymer diaphragm ensures clean, natural high-frequency response
        • Compact ferrite-based motor structure optimized for efficient sound systems



        Product details Beyma CD-10Fe/N

        Beyma CD-10Fe/N Compression Driver



        The Beyma CD-10Fe/N is a 1” exit high-frequency compression driver designed for efficient sound reproduction in compact systems. It features a 1.75” ultra-light edgewound aluminum ribbon voice coil, enabling fast transient response and excellent thermal handling. This driver delivers 70 W AES power and 140 W program power above 1.2 kHz, with a high sensitivity of 109 dB (1W/1m). At the core of the CD-10Fe/N is a PM-4 polymer diaphragm, chosen for its natural tonal characteristics and durability. The ferrite magnetic assembly produces a 1.65 T flux density and a Bl factor of 6.6 N/A, ensuring reliable and clean high-frequency output across its wide frequency range of 0.7 to 19 kHz. Physically compact, the CD-10Fe/N measures just 100 mm in diameter and 62 mm in depth. It features flexible mounting options: three M5 threaded holes (120° apart on a 57 mm circle) and two additional holes (180° apart on a 76.2 mm circle), making it compatible with a variety of horn designs and enclosures. Weighing only 1.3 kg, it’s a lightweight yet robust solution for both portable PA systems and installed sound applications.

        Toon meer

        Specificaties

        Artikelnummer
        CD-10Fe/N
        EAN
        8435469044456
        Tweeter type
        Compression Driver
        Cone / Dome Diameter
        1.75”
        Belastbaarheid (RMS)
        140 Watts
        Impedantie (Z)
        8 Ω
        Gevoeligheid (SPL bij 1m / 2.83V)
        109 dB
        Frequentierespons
        700 - 19.000 Hz
        Gelijstroomweerstand (Re)
        4,3 Ω
        Totale buitendiameter
        100 mm
        Diepte
        62 mm
        Bevestigingstype
        3 Screws, 5.00 mm

        Toon meer
