        18LX60V2/S Subwoofer

        Beyma 18LX60V2/S Subwoofer

        €279,95

        6 Op voorraad

        Toevoegen aan winkelwagen

        Beyma 18LX60V2/S Subwoofer

        0 reviews
        0 van 5
        0 reviews
        5 sterren
        0%
        4 sterren
        0%
        3 sterren
        0%
        2 sterren
        0%
        1 ster
        0%
        Bekijk alle reviews
        Merk: Beyma
        Toon alle Nieuwe producten
        18" | 8 Ω
        18LX60V2/S Subwoofer
        18LX60V2/S Subwoofer
        18LX60V2/S Subwoofer
        18LX60V2/S Subwoofer
        € 231,36€ 279,95 6 Op voorraad
        • -5% Bestel 4 voor slechts € 265,95 per stuk
        +-
        Toevoegen aan winkelwagen

        Buy now, pay later

        • Gratis verzonden (NL & BE)
        • Nu besteld, dinsdag bezorgd
        • Ten minste twee jaar garantie
        • 45 dagen bedenktijd voor retourneren
        • Klantbeoordeling:
        Zakelijke offerteaanvraag
        Heeft u vragen over dit product?

        Heeft u vragen over dit product?

        Onze klantenservice helpt u graag verder!

        18LX60V2/S Subwoofer
        18LX60V2/S Subwoofer
        18LX60V2/S Subwoofer
        18LX60V2/S Subwoofer

        Productomschrijving Beyma 18LX60V2/S Subwoofer

        The Beyma 18LX60V2/S is a versatile 18” subwoofer that delivers powerful bass and high sensitivity, making it an ideal choice for professional sound reinforcement systems and robust DIY audio builds. Optimized with modern design tools and durable materials, it balances efficiency, control, and reliability.



        Highlights of the Beyma 18LX60V2/S Subwoofer

        • 700W AES power handling and 1,400W program power with 98 dB sensitivity
        • 4” DUO double-layer in/out voice coil for improved power handling and thermal performance
        • FEA-optimized magnetic circuit and CONEX spider for increased durability
        • Weatherproof cone and Xmax of ±9 mm with 47 mm peak-to-peak excursion



        Product details Beyma 18LX60V2/S Subwoofer

        Beyma 18LX60V2/S Low Frequency Transducer



        The Beyma 18LX60V2/S is an 18” low-frequency driver designed for demanding subwoofer applications where high output, reliability, and extended low-frequency response are critical. With an AES-rated power capacity of 700 watts and program power handling up to 1,400 watts, it delivers substantial performance with excellent efficiency thanks to its 98 dB sensitivity.

        This driver features a rugged 4” DUO in/out copper voice coil that enhances thermal management and reliability, even during prolonged operation. The optimized magnetic structure—developed using finite element analysis (FEA)—supports a strong Bl factor of 21.8 N/A, contributing to precise and responsive low-end reproduction. The unit's linear excursion of ±9 mm (Xmax) and 47 mm mechanical excursion limit provide clean, high-SPL bass with minimal distortion.

        The 18LX60V2/S employs a weatherproof cone treated on both sides and is supported by a CONEX spider for consistent performance and long-term mechanical stability. Designed for bass-reflex enclosures tuned to 35 Hz (Vb = 250 L), the driver covers a frequency range from 25 to 1,000 Hz, making it a suitable fit for a wide array of professional subwoofer applications.

        Toon meer

        Specificaties

        Artikelnummer
        18LX60V2/S
        EAN
        8435469044173
        Woofer series
        Beyma LX60 series
        Woofer type
        Subwoofer
        Nominale diameter
        18"
        Belastbaarheid (RMS)
        700 Watts
        Belastbaarheid (max)
        1.400 Watts
        Impedantie (Z)
        8 Ω
        Gevoeligheid (SPL bij 1m / 2.83V)
        98 dB
        Frequentierespons
        25-1.000 Hz
        Spreekspoeldiameter
        101.6 mm
        Gelijkstroomweerstand (Re)
        5.1 Ω
        Spreekspoelinductie (Le)
        2.1 mH
        Resonantiefrequentie (Fs)
        35 Hz
        Mechanische Q (Qms)
        15.7
        Elektrische Q (Qes)
        0.5
        Totale Q (Qts)
        0.48
        Bewegende massa (Mms)
        0.215 kg
        Compliantie van de ophanging (Cms)
        94,5 µm / N
        Effectief oppervlak (Sd)
        0,132 m²
        Maximaal verplaatst volume (Vd)
        1056 cm³
        Krachtsfactor (BL)
        21,8 N/A
        Equivalentvolume (Vas)
        236 Liters
        Maximale excursie (Xmax)
        +/- 8 mm
        Driver's Mechanical Losses (Rms)
        3,1 kg / s
        Totale buitendiameter
        461 mm
        Totale diepte
        193 mm
        Montagegatdiameter
        415 mm
        Bolt Circle Diameter
        438 mm
        # Bevestigingsgaten
        8
        Diameter bevestigingsgaten
        7.5 mm

        Toon meer
