        15LEX1000Nd Subwoofer 8 Ohm

        Beyma 15LEX1000Nd Subwoofer 8 Ohm

        €339,95

        2 Op voorraad

        Toevoegen aan winkelwagen

        Beyma 15LEX1000Nd Subwoofer 8 Ohm

        0 reviews
        0 van 5
        0 reviews
        5 sterren
        0%
        4 sterren
        0%
        3 sterren
        0%
        2 sterren
        0%
        1 ster
        0%
        Bekijk alle reviews
        Merk: Beyma
        Toon alle Nieuwe producten
        15" | 8 Ω
        15LEX1000Nd Subwoofer 8 Ohm
        15LEX1000Nd Subwoofer 8 Ohm
        15LEX1000Nd Subwoofer 8 Ohm
        15LEX1000Nd Subwoofer 8 Ohm
        € 280,95€ 339,95 2 Op voorraad
        • -5% Bestel 4 voor slechts € 322,95 per stuk
        +-
        Toevoegen aan winkelwagen

        Buy now, pay later

        • Gratis verzonden (NL & BE)
        • Voor 16u besteld, vandaag verstuurd
        • Ten minste twee jaar garantie
        • 45 dagen bedenktijd voor retourneren
        • Klantbeoordeling:
        Zakelijke offerteaanvraag
        Heeft u vragen over dit product?

        Heeft u vragen over dit product?

        Onze klantenservice helpt u graag verder!

        15LEX1000Nd Subwoofer 8 Ohm
        15LEX1000Nd Subwoofer 8 Ohm
        15LEX1000Nd Subwoofer 8 Ohm
        15LEX1000Nd Subwoofer 8 Ohm

        Voor- en nadelen

        Volgens onze specialisten
        • Weatherproof cone with treatment for both sides
        • Optimized for direct radiation and band-pass subwoofer applications

        Productomschrijving Beyma 15LEX1000Nd Subwoofer

        The Beyma 15LEX1000Nd is a high-efficiency 15” neodymium subwoofer designed to deliver clean, deep bass in compact enclosures. It combines advanced cooling, precise linearity, and lightweight construction for top performance in professional sound reinforcement and high-end DIY systems.



        Highlights of the Beyma 15LEX1000Nd Subwoofer

        • 1,000W AES and 2,000W program power with 97 dB sensitivity
        • 3.5” DUO in/out copper voice coil with ±11 mm linear excursion
        • Exclusive Malt Cross® cooling system for reduced power compression
        • FEA-optimized neodymium magnet and weatherproof treated cone



        Product details Beyma 15LEX1000Nd Subwoofer

        Beyma 15LEX1000Nd Low Frequency Transducer



        The Beyma 15LEX1000Nd is a professional-grade 15” low-frequency driver built for applications requiring high output and clean bass in a compact format. It supports 1,000W AES continuous power and up to 2,000W program power, delivering high SPL performance with minimal distortion. With a sensitivity of 97 dB (1W/1m) and a frequency range of 40–1,500 Hz, this driver excels in both direct radiation and band-pass subwoofer setups.

        The motor system features a neodymium magnet optimized using finite element analysis (FEA) to deliver high efficiency and a strong Bl factor of 21.9 N/A. A 3.5” DUO in/out copper voice coil supports extended controlled excursion of ±11 mm, and a total peak-to-peak mechanical limit of 60 mm ensures robust handling of demanding audio signals. The lightweight 0.147 kg moving mass contributes to a tight, responsive bass response.

        Enhanced thermal stability is provided by Beyma’s patented Malt Cross® cooling system, which reduces power compression during extended use. The cone is weatherproof-treated on both sides for durability in varied environments. Recommended for bass-reflex enclosures (Vb = 115 L, Fb = 40 Hz), the 15LEX1000Nd is a lightweight yet powerful solution for compact subwoofer applications.

        Toon meer

        Specificaties

        Artikelnummer
        15LEX1000Nd
        EAN
        8435469043572
        Woofer series
        Beyma LEX series
        Woofer type
        Subwoofer
        Nominale diameter
        15"
        Belastbaarheid (RMS)
        1000 Watts
        Continuous Program Power
        2.000 Watts
        Impedantie (Z)
        8 Ω
        Gevoeligheid (SPL bij 1m / 2.83V)
        97 dB
        Frequentierespons
        40-1.500 Hz
        Spreekspoeldiameter
        88.9 mm
        Gelijkstroomweerstand (Re)
        5.2 Ω
        Spreekspoelinductie (Le)
        1.1 mH
        Resonantiefrequentie (Fs)
        41 Hz
        Mechanische Q (Qms)
        3.9
        Elektrische Q (Qes)
        0.41
        Totale Q (Qts)
        0.37
        Bewegende massa (Mms)
        0.147 kg
        Compliantie van de ophanging (Cms)
        103 µm / N
        Effectief oppervlak (Sd)
        0,088 m²
        Maximaal verplaatst volume (Vd)
        968 cm³
        Krachtsfactor (BL)
        21,9 N/A
        Equivalentvolume (Vas)
        113 Liters
        Maximale excursie (Xmax)
        +/- 11 mm
        Driver's Mechanical Losses (Rms)
        9,7 kg / s
        Spreekspoel vormermateriaal
        Copper
        Dual Voice Coil
        DUO double layer in/out copper voice coil
        Magneetmateriaal
        neodymium
        Totale buitendiameter
        393 mm
        Totale diepte
        189 mm
        Montagegatdiameter
        352 mm
        Bolt Circle Diameter
        373 mm
        # Bevestigingsgaten
        8
        Diameter bevestigingsgaten
        7.0 mm
