        10BR60/V2 Bass-midwoofer

        Beyma 10BR60/V2 Bass-midwoofer

        €109,95

        7 Op voorraad10+ verwacht op 02-01-2026

        Toevoegen aan winkelwagen

        Beyma 10BR60/V2 Bass-midwoofer

        1 reviews
        5 van 5
        1 reviews
        5 sterren
        100%
        4 sterren
        0%
        3 sterren
        0%
        2 sterren
        0%
        1 ster
        0%
        Bekijk alle reviews
        Merk: Beyma
        Toon alle Nieuwe producten
        10" | 8 Ω
        10BR60/V2 Bass-midwoofer
        10BR60/V2 Bass-midwoofer
        10BR60/V2 Bass-midwoofer
        10BR60/V2 Bass-midwoofer
        10BR60/V2 Bass-midwoofer
        10BR60/V2 Bass-midwoofer
        10BR60/V2 Bass-midwoofer
        10BR60/V2 Bass-midwoofer
        10BR60/V2 Bass-midwoofer
        10BR60/V2 Bass-midwoofer
        10BR60/V2 Bass-midwoofer
        10BR60/V2 Bass-midwoofer
        10BR60/V2 Bass-midwoofer
        € 90,87€ 109,95 7 Op voorraad10+ verwacht op 02-01-2026
        • -5% Bestel 4 voor slechts € 104,45 per stuk
        +-
        Toevoegen aan winkelwagen

        Buy now, pay later

        • Gratis verzonden (NL & BE)
        • Nu besteld, dinsdag bezorgd
        • Ten minste twee jaar garantie
        • 45 dagen bedenktijd voor retourneren
        • Klantbeoordeling:
        Zakelijke offerteaanvraag
        Heeft u vragen over dit product?

        Heeft u vragen over dit product?

        Onze klantenservice helpt u graag verder!

        10BR60/V2 Bass-midwoofer
        10BR60/V2 Bass-midwoofer
        10BR60/V2 Bass-midwoofer
        10BR60/V2 Bass-midwoofer
        10BR60/V2 Bass-midwoofer
        10BR60/V2 Bass-midwoofer
        10BR60/V2 Bass-midwoofer
        10BR60/V2 Bass-midwoofer
        10BR60/V2 Bass-midwoofer
        10BR60/V2 Bass-midwoofer
        10BR60/V2 Bass-midwoofer
        10BR60/V2 Bass-midwoofer
        10BR60/V2 Bass-midwoofer
        10BR60/V2 Bass-midwoofer

        Voor- en nadelen

        Volgens onze specialisten
        • Ferrite magnet, Designed for low frequency reproduction

        Productomschrijving Beyma 10BR60/V2 Bass-midwoofer

        The Beyma 10BR60V2 is a 10” low-frequency transducer built for reliable performance in compact systems. With a ferrite magnet and 2” voice coil, it delivers extended bass response with solid efficiency, making it ideal for small PA setups and bass reinforcement projects.



        Highlights of the Beyma 10BR60V2

        • 100 W AES / 200 W program power with 92 dB sensitivity
        • 2” copper voice coil on ferrite magnet motor
        • ±6.5 mm Xmax and 31 mm peak-to-peak damage excursion
        • Extended low-frequency response down to 30 Hz with Fs of 29 Hz



        Product details Beyma 10BR60V2

        Beyma 10BR60V2 Low Frequency Transducer



        The Beyma 10BR60V2 is a compact 10-inch woofer designed for low-frequency reinforcement in small speaker systems. With a power capacity of 100 W AES (200 W program), it provides efficient output through a 2” copper voice coil and ferrite magnet assembly. Its sensitivity of 92 dB (1W/1m) ensures responsive performance even with lower-powered amplification. Operating across a frequency range of 30 Hz to 5,000 Hz, the 10BR60V2 is capable of deep bass response thanks to its low resonant frequency of 29 Hz. The mechanical structure supports a ±6.5 mm Xmax and 31 mm peak-to-peak excursion before damage, delivering reliable, distortion-free low-end performance. Built for bass-reflex enclosures from 30 to 100 liters, the 10BR60V2 combines versatility with compactness. It weighs just 2.9 kg and has a depth of 117 mm, making it easy to integrate into portable cabinets, home audio systems, and entry-level PA builds where tight, musical bass is essential.

        Toon meer

        Specificaties

        Artikelnummer
        10BR60/V2
        EAN
        8435469045880
        Woofer type
        Low Frequency Transducer
        Nominale diameter
        10"
        Belastbaarheid (RMS)
        100 Watts
        Continuous Program Power
        200 Watts
        Impedantie (Z)
        8 Ω
        Gevoeligheid (SPL bij 1m / 2.83V)
        92 dB
        Frequentierespons
        30-5.000 Hz
        Spreekspoeldiameter
        2"
        Gelijkstroomweerstand (Re)
        6.5 Ω
        Spreekspoelinductie (Le)
        1.14 mH
        Resonantiefrequentie (Fs)
        29 Hz
        Mechanische Q (Qms)
        3.3
        Elektrische Q (Qes)
        0.44
        Totale Q (Qts)
        0.39
        Bewegende massa (Mms)
        0,044 kg
        Compliantie van de ophanging (Cms)
        693 µm / N
        Effectief oppervlak (Sd)
        0,038 m²
        Maximaal verplaatst volume (Vd)
        247 cm³
        Krachtsfactor (BL)
        10,9 N/A
        Equivalentvolume (Vas)
        142 Liters
        Maximale excursie (Xmax)
        +/- 6.5 mm
        Driver's Mechanical Losses (Rms)
        2,4 kg / s
        Magneetmateriaal
        Ferrite
        Totale buitendiameter
        260.5 mm
        Totale diepte
        117 mm
        Montagegatdiameter
        228 mm
        Bolt Circle Diameter
        243.5 mm
        # Bevestigingsgaten
        8
        Diameter bevestigingsgaten
        6.00 mm

        Toon meer

        Reviews

        1 reviews
        Schrijf een review
        5 van 5
        Das Teil ist einfach mechanisch und elektrisch top.
