      Vantaggi e svantaggi

      Secondo i nostri esperti
      • The dome and surround are critically doped for smoothness and consistency of response.
      • The termination braids are hidden inside the unit and are not visible.

      Descrizione del prodotto Volt Loudspeakers VM753E Mid-range Dome

      The Volt Loudspeakers VM753E is an 8 ohm mid-range dome designed for high-fidelity audio applications. This driver is known for its exceptional performance and smooth response, making it a popular choice among audiophiles and DIY audio enthusiasts.



      Highlights of the Volt Loudspeakers VM753E Mid-range Dome

      • 3" (75mm) diameter dome loaded by a short, front-mounted horn
      • Lightweight single-layer copper coil for high excursions
      • Critically doped dome and surround for smoothness and consistency
      • FEA designed 155mm ceramic magnet system for high efficiency



      Product details of the Volt Loudspeakers VM753E Mid-range Dome

      Volt Loudspeakers VM753E Mid-range Dome



      The VM753E from Volt Loudspeakers is an 8 ohm version of their renowned 3" (75mm) diameter dome midrange unit, loaded with a short front-mounted horn. This design allows for high excursions at the lower end of its operating range, enhancing the overall audio performance. The dome and surround are doped for smooth response and consistency, while the second, rear surround ensures coil stability. The driver is built with an FEA-designed 155mm ceramic magnet system, which provides high efficiency and is mounted on a solid, machined aluminum chassis. The unit is rear-mounted using M5 threaded inserts and connects via 6.4mm (0.25") spade terminals for secure and flexible installation options.



      The VM753E is ideal for applications requiring high power handling (100W AES) and high sensitivity (92 dB/W/m), with a frequency response range of 500 to 4000 Hz. Its robust construction and replaceable dome/coil assembly make it a reliable and serviceable choice for demanding audio setups.

      Show more

      Specifiche

      Numero dell'articolo:
      VM753E
      EAN
      9504584886971
      Tipo di woofer
      Midrange Dome
      Diametro nominale
      3 "
      Gestione della potenza (RMS)
      100 Watts
      Impedenza (Z)
      16 Ω
      Sensibilità (SPL a 1m / 2,83V)
      92 dB
      Risposta in frequenza
      500 - 4000 Hz
      Diametro della bobina mobile
      75 mm
      Resistenza DC (Re)
      10.6 Ω
      Induttanza della bobina mobile (Le)
      0.24 mH
      Frequenza di risonanza (Fs)
      450 Hz
      Fattore di merito meccanico (Qms)
      4.99
      Fattore di merito elettromagnetico (Qes)
      1.41
      Fattore di merito totale (Qts)
      1.10
      Superficie del cono (Sd)
      57 cm²
      Volume di spostamento (Vd)
      5.7 cm³
      Volume equivalente di cedevolezza (Vas)
      0.16 Litres
      Escursione lineare massima (Xmax)
      1 mm
      Materiale del cono / diaframma
      Copper
      Materiale del cestello / telaio
      Aluminum
      Diametro esterno complessivo
      190 mm
      Profondità complessiva
      81 mm
      Diametro del ritaglio del pannello frontale
      152.5 mm
      # Numero di fori di montaggio
      4
      Diametro dei fori di montaggio
      5.2
