      Descrizione del prodotto Volt Loudspeakers VM753 Mid-range Dome

      The Volt Loudspeakers VM753 Mid-range Dome is a high-quality audio component designed for audiophiles and DIY speaker builders. This 16-ohm, 3-inch (75mm) dome unit is horn-loaded and features advanced materials and engineering for superior performance.



      Highlights of the Volt Loudspeakers VM753 Mid-range Dome

      • 3-inch (75mm) diameter soft dome midrange
      • 16-ohm impedance for compatibility with various systems
      • Lightweight single-layer copper coil for high excursions
      • Critically doped dome and surround for smooth response



      Product details Volt Loudspeakers VM753 Mid-range Dome

      Volt Loudspeakers VM753 Mid-range Dome Unit



      The Volt VM753 is a horn-loaded 3-inch midrange dome designed to deliver clear and detailed midrange frequencies. It features a 16-ohm impedance and utilizes a lightweight single-layer round wire copper coil that extends slightly longer than the focused magnet gap, allowing for high excursions at the lower end of its operating range. The dome and surround are critically doped to ensure smoothness and consistency of response, while the addition of a second, rear surround maintains coil stability. The unit's FEA-designed magnet system incorporates a substantial ceramic magnet for high efficiency, mounted on a sturdy die-cast aluminum chassis. This driver is engineered for rear mounting and includes M5 threaded inserts for secure installation.



      The VM753 is recognized for its high sensitivity (92.5 dB at 2.83V/1m) and can handle a nominal power of 100 watts, making it a robust choice for high-performance audio systems. The unit's frequency range extends from 500 Hz to 4000 Hz, with a free air resonance of 450 Hz, ensuring it can accurately reproduce critical midrange frequencies. With these specifications, the VM753 is a preferred replacement for the discontinued ATC SM75-150, offering a blend of traditional quality and modern engineering for exceptional audio performance.

      Show more

      Specifiche

      Numero dell'articolo:
      VM753
      EAN
      9507238523536
      Tipo di woofer
      Midrange Woofer Dome
      Diametro nominale
      3 ”
      Gestione della potenza (RMS)
      100 Watts
      Impedenza (Z)
      16 Ω
      Sensibilità (SPL a 1m / 2,83V)
      92 dB
      Risposta in frequenza
      500 - 4000 Hz
      Diametro della bobina mobile
      75 mm
      Resistenza DC (Re)
      10.6 Ω
      Induttanza della bobina mobile (Le)
      0.24 mH
      Frequenza di risonanza (Fs)
      450 Hz
      Fattore di merito meccanico (Qms)
      4.99
      Fattore di merito elettromagnetico (Qes)
      1.41
      Fattore di merito totale (Qts)
      1.10
      Superficie del cono (Sd)
      57 cm²
      Volume di spostamento (Vd)
      5.7 cm³
      Supporto della bobina mobile
      Kapton
      Materiale del cestello / telaio
      Machined Aluminium
      Diametro esterno complessivo
      190 mm
      Profondità complessiva
      81 mm
      Diametro del ritaglio del pannello frontale
      153 mm
      # Numero di fori di montaggio
      4
      Diametro dei fori di montaggio
      5.2 mm
