      Gold Series 11M/4631G05 Woofer a Gamma Media

      Scan-Speak Gold Series 11M/4631G05 Woofer a Gamma Media

      €299,95

      Non disponibile

      Scan-Speak Gold Series 11M/4631G05 Woofer a Gamma Media

      0 reviews
      0 da 5
      0 reviews
      5 stars
      0%
      4 stars
      0%
      3 stars
      0%
      2 stars
      0%
      1 stella
      0%
      Leggi le recensioni
      Marchio: Scan-Speak
      € 247,89€ 299,95 Esaurito
      • -5% Acquista 4 per soli € 284,95 per pezzo

      Buy now, pay later

      • Spedizione gratuita a partire da € 199
      • Presto di nuovo disponibile
      • Minimo due anni di garanzia
      • Periodo di recesso di 45 giorni per i resi
      • Dicono di noi:
      Richiedi preventivo
      Hai una domanda su questo prodotto?

      Hai una domanda su questo prodotto?

      Il nostro addetto è lieto di aiutarvi a trovare il prodotto giusto

      Vantaggi e svantaggi

      Secondo i nostri esperti
      • Optimized for automotive use

      Descrizione del prodotto Scan-Speak Gold Series 11M/4631G05 Woofer a Gamma Media

      The GOLD SERIES are specially selected units from Scan-Speak’s well-known home audio speakers. Which have been upgraded and optimized for automotive use. This series enables audiophiles to experience in their vehicle the – TRUE TO LIVE – that they enjoy from their high-end home audio system.



      Highlights

      • Sliced Paper Cone
      • Compact Neodymium Magnet System
      • Low-Loss Linear Suspension
      • Robust Alu Chassis
      • High Grade Neo Magnet
      • Protective Magnet Cup with Grill over Pole Vent



      Product details

      Scan-Speak Gold Series 11M/4631G05 Car Mid-range Woofer



      The Scan-Speak Gold Series 11M/4631G05 Mid-range Woofer is a high-performance speaker driver that is designed for automotive use. It is a 4.5-inch driver with a nominal impedance of 4 ohms. It has a sensitivity of 90 dB, which means that it will produce a relatively high sound level for a given input power. The frequency response of the driver is 200 Hz to 3.5 kHz, which covers the mid-range frequencies that are important for speech and music.



      The 11M/4631G05 is made with a gold-plated aluminum voice coil that is wound on a high-temperature former. This gives the driver good power handling and heat dissipation capabilities. The cone is made of Scan-Speak's proprietary MSP (Magnesium Silicate Polymer) material, which is known for its excellent stiffness and damping properties. This results in a driver that is able to reproduce mid-range frequencies with clarity and accuracy.

      Show more

      Specifiche

      Numero dell'articolo:
      11M/4631G05
      EAN
      8785256848263
      Tipo di woofer
      Midrange woofer Automotive
      Diametro nominale
      4.5 Inch
      Gestione della potenza (RMS)
      40 Watts
      Gestione della potenza (max)
      70 Watt
      Impedenza (Z)
      4 Ohm
      Sensibilità (SPL a 1m / 2,83V)
      90 dB
      Risposta in frequenza
      85-10000 Hz
      Diametro della bobina mobile
      38 mm
      Resistenza DC (Re)
      3.3 Ohm
      Induttanza della bobina mobile (Le)
      0.06 mH
      Frequenza di risonanza (Fs)
      68 Hz
      Fattore di merito meccanico (Qms)
      4.54
      Fattore di merito elettromagnetico (Qes)
      0.33
      Fattore di merito totale (Qts)
      0.31
      Massa del diaframma incl. la massa dell'aria (Mms)
      7.1 g
      Cedevolezza meccanica della sospensione (Cms)
      0.77 mm/N
      Superficie del cono (Sd)
      50 cm2
      Prodotto BL (BL)
      5.5 Tm
      Volume equivalente di cedevolezza (Vas)
      2.7 Litres
      Escursione lineare massima (Xmax)
      7 mm
      Materiale del cestello / telaio
      Aluminium
      Diametro esterno complessivo
      115.1 mm
      Diametro del ritaglio del pannello frontale
      93.2 mm
      # Numero di fori di montaggio
      3
      Diametro dei fori di montaggio
      4.2 mm
      Volume per cassa reflex
      1.5 Litres

      Show more
