      SB16PFCR25-8 Woofer a Gamma Media

      SB Acoustics SB16PFCR25-8 Woofer a Gamma Media

      €31,45

      3 In magazzino10+ Arrivo previsto il 19-12-2025

      SB Acoustics SB16PFCR25-8 Woofer a Gamma Media

      1 reviews
      5 da 5
      1 reviews
      5 stars
      100%
      4 stars
      0%
      3 stars
      0%
      2 stars
      0%
      1 stella
      0%
      Leggi le recensioni
      Marchio: SB Acoustics
      € 25,99€ 31,45 3 In magazzino10+ Arrivo previsto il 19-12-2025
      • -5% Acquista 4 per soli € 29,88 per pezzo

      Buy now, pay later

      • Spedizione gratuita a partire da € 199
      • Ordinato ora, spedito lunedì
      • Minimo due anni di garanzia
      • Periodo di recesso di 45 giorni per i resi
      • Dicono di noi:
      Richiedi preventivo
      Hai una domanda su questo prodotto?

      Hai una domanda su questo prodotto?

      Il nostro addetto è lieto di aiutarvi a trovare il prodotto giusto

      Descrizione del prodotto SB Acoustics SB16PFCR25-8 Woofer a Gamma Media

      The SB Acoustics SB16PFCR25-8 is a high-quality mid-range woofer that is perfect for a variety of speaker applications. It offers excellent performance at an affordable price. It is also very easy to install and use.



      Highlights

      • Paper cone for smooth and natural sound
      • Vented reinforced plastic chassis for low resonance
      • Optimized motor system for high power handling
      • Ferrite magnet for high efficiency
      • Low damping rubber surround for improved transient response
      • Vented coil former for low compression
      • Non-resonant long life lead wires



      Product details

      SB Acoustics SB16PFCR25-8 Mid-range Woofer



      The SB Acoustics SB16PFCR25-8 is a 6-inch mid-range woofer with a paper cone, vented reinforced plastic chassis, and an optimized motor system with a high power ferrite magnet. It has a frequency response of 50Hz to 5kHz, a sensitivity of 88dB, and a power handling capacity of 250W RMS. It is suitable for use in a variety of speaker applications, including bookshelf speakers, floorstanding speakers, and center channel speakers.

      Show more

      Specifiche

      Numero dell'articolo:
      SB16PFCR25-8
      EAN
      8785256859870
      Tipo di woofer
      Bass-Midwoofer
      Diametro nominale
      6″
      Gestione della potenza (RMS)
      40 Watts
      Impedenza (Z)
      8 Ω
      Sensibilità (SPL a 1m / 2,83V)
      87 dB
      Diametro della bobina mobile
      25.4 mm
      Resistenza DC (Re)
      5.6 Ω
      Induttanza della bobina mobile (Le)
      0.77 mH
      Frequenza di risonanza (Fs)
      38 Hz
      Fattore di merito meccanico (Qms)
      2.5
      Fattore di merito elettromagnetico (Qes)
      0.48
      Fattore di merito totale (Qts)
      0.40
      Massa del diaframma incl. la massa dell'aria (Mms)
      13.8 g
      Cedevolezza meccanica della sospensione (Cms)
      1.25 mm/N
      Superficie del cono (Sd)
      124 cm2
      Prodotto BL (BL)
      6.2 Tm
      Volume equivalente di cedevolezza (Vas)
      27 Liters
      Escursione lineare massima (Xmax)
      (p-p) 9 mm
      Perdite meccaniche del driver (Rms)
      1.4 kg/s
      Diametro esterno complessivo
      176 mm
      Profondità complessiva
      88.3 mm
      Diametro del ritaglio del pannello frontale
      144.5 mm
      # Numero di fori di montaggio
      4
      Diametro dei fori di montaggio
      4.3 mm
