      SB16PFCR25-4 Woofer Medio-Bassi

      SB Acoustics SB16PFCR25-4 Woofer Medio-Bassi

      €36,45

      10+ In magazzino

      SB Acoustics SB16PFCR25-4 Woofer Medio-Bassi

      1 reviews
      5 da 5
      1 reviews
      5 stars
      100%
      4 stars
      0%
      3 stars
      0%
      2 stars
      0%
      1 stella
      0%
      Leggi le recensioni
      Marchio: SB Acoustics
      € 30,12€ 36,45 10+ In magazzino
      • -5% Acquista 4 per soli € 34,63 per pezzo

      Buy now, pay later

      • Spedizione gratuita a partire da € 199
      • Ordinato prima delle 16:00, spedito oggi
      • Minimo due anni di garanzia
      • Periodo di recesso di 45 giorni per i resi
      • Dicono di noi:
      Richiedi preventivo
      Hai una domanda su questo prodotto?

      Hai una domanda su questo prodotto?

      Il nostro addetto è lieto di aiutarvi a trovare il prodotto giusto

      Vantaggi e svantaggi

      Secondo i nostri esperti
      • Vented coil former for low compression and Soft low damping rubber surround for improved transient response

      Descrizione del prodotto SB Acoustics SB16PFCR25-4 Woofer Medio-Bassi

      The SB Acoustics SB16PFCR25-4 is a 6" mid-woofer with a 25mm voice coil and a vented reinforced plastic chassis. It features a proprietary cone material with natural fibers made in-house and a soft low damping rubber surround for improved transient response. The optimized motor system and vented coil former for low compression are also noteworthy features of this mid-woofer.



      Highlights

      • Vented reinforced plastic chassis
      • Proprietary cone material with natural fibers made in-house
      • Soft low damping rubber surround for improved transient response
      • Optimized motor system
      • Vented coil former for low compression
      • Non-resonant long life lead wires



      Product details

      SB Acoustics SB16PFCR25-4 Paper Bass-midwoofer



      The SB Acoustics SB16PFCR25-4 is a mid-woofer that is designed to reproduce frequencies in the range of 35 Hz to 4 kHz. It is suitable for use in a two-way speaker system or as a mid-woofer in a three-way system. The vented reinforced plastic chassis helps to reduce unwanted resonances and the proprietary cone material with natural fibers made in-house provides a good balance between stiffness and damping. The soft low damping rubber surround helps to improve the transient response of the driver. The optimized motor system and vented coil former for low compression help to reduce distortion and improve power handling.



      The SB Acoustics SB16PFCR25-4 is a 6-inch paper cone woofer with a 4-ohm nominal impedance. It has a free-air resonance of 35 Hz and a sensitivity of 89.5 dB. This is a versatile woofer that can be used in a variety of applications, including home audio, car audio, and professional audio. It is well-suited for use in sealed and ported enclosures, and it can handle up to 40 watts of continuous power.

      Show more

      Specifiche

      Numero dell'articolo:
      SB16PFCR25-4
      EAN
      8785256848157
      Serie del woofer
      SB Acoustics PFC Paper series
      Diametro nominale
      176 mm
      Gestione della potenza (RMS)
      40 Watts
      Impedenza (Z)
      4 Ohm
      Sensibilità (SPL a 1m / 2,83V)
      89.5 dB
      Risposta in frequenza
      35 Hz to 4 kHz
      Diametro della bobina mobile
      25.4 mm
      Resistenza DC (Re)
      3.2 Ohm
      Induttanza della bobina mobile (Le)
      0.56 mH
      Frequenza di risonanza (Fs)
      35 Hz
      Fattore di merito meccanico (Qms)
      2.76
      Fattore di merito elettromagnetico (Qes)
      0.39
      Fattore di merito totale (Qts)
      0.34
      Massa del diaframma incl. la massa dell'aria (Mms)
      13.8 g
      Cedevolezza meccanica della sospensione (Cms)
      1.5 mm/N
      Superficie del cono (Sd)
      124 cm2
      Prodotto BL (BL)
      5.0 Tm
      Volume equivalente di cedevolezza (Vas)
      32.7 liters
      Escursione lineare massima (Xmax)
      4.5 mm
      Materiale del cestello / telaio
      Vented reinforced plastic
      Diametro esterno complessivo
      176 mm
      # Numero di fori di montaggio
      4
      Diametro dei fori di montaggio
      4.3 mm

      Show more

      5 di 5
      Great woofer for DIY projects, can be used as a midrange in a 3-way or as a mid-bass in a 2-way ported or sealed. very versatile
      Da Hugo Mottet on 10 Aprile 2025
