      PLS-P830987 Woofer a Gamma Completa

      Peerless by Tymphany PLS-P830987 Woofer a Gamma Completa

      €29,95

      10+ In magazzino

      Peerless by Tymphany PLS-P830987 Woofer a Gamma Completa

      0 reviews
      0 da 5
      0 reviews
      5 stars
      0%
      4 stars
      0%
      3 stars
      0%
      2 stars
      0%
      1 stella
      0%
      Leggi le recensioni
      € 24,75€ 29,95 10+ In magazzino
      • -5% Acquista 4 per soli € 28,45 per pezzo

      Buy now, pay later

      • Spedizione gratuita a partire da € 199
      • Ordinato ora, spedito oggi
      • Minimo due anni di garanzia
      • Periodo di recesso di 45 giorni per i resi
      • Dicono di noi:
      Richiedi preventivo
      Hai una domanda su questo prodotto?

      Hai una domanda su questo prodotto?

      Il nostro addetto è lieto di aiutarvi a trovare il prodotto giusto

      Descrizione del prodotto Peerless by Tymphany PLS-P830987 Woofer a Gamma Completa

      Tymphany/Peerless full range drivers set the standard for quality audio in products including flat panel televisions and sound bars, MP3 and cell phone docking stations, and multimedia PCs.



      Highlights

      • Neodymium magnet
      • Double-vented motor
      • Anodized aluminum center dome
      • Distortion-reducing semi-progressive surround
      • Inverted half-roll rubber surround
      • Copper pole piece cap controls impedance



      Product details

      Peerless by Tymphany PLS-P830987 3" Full Range Woofer



      This 3 inch 8 Ω member of the PLS family sets a high standard, for compact full range drivers intended for applications such as television soundbars and compact music systems. Design features in this family include a damped plastic basket with venting under the spider to aid cooling of the motor, a neodymium magnet motor with copper cap to lower coil inductance, providing low distortion at low frequencies and extended high frequency response. A black anodized aluminium cone is employed on the driver, along with a black anodized aluminium dust cap coupled directly to the voice coil. Additionally, the cones come equipped with special-designed large roll rubber surrounds, which allow for a dynamic linear response to high excursion input signals.

      Show more

      Specifiche

      Numero dell'articolo:
      PLS-P830987
      EAN
      0844632083884
      Serie del woofer
      Peerless by Tymphany PLS series
      Tipo di woofer
      Full-Range
      Diametro nominale
      3" | 78 x 78 mm
      Gestione della potenza (RMS)
      25 Watts
      Impedenza (Z)
      8 Ω
      Sensibilità (SPL a 1m / 2,83V)
      81.8 dB
      Risposta in frequenza
      100 - 12000 Hz
      Diametro della bobina mobile
      25.7 mm
      Resistenza DC (Re)
      6.2 Ω
      Induttanza della bobina mobile (Le)
      0.119 mH
      Frequenza di risonanza (Fs)
      110 Hz
      Fattore di merito meccanico (Qms)
      6.74
      Fattore di merito elettromagnetico (Qes)
      1.22
      Fattore di merito totale (Qts)
      1
      Massa del diaframma incl. la massa dell'aria (Mms)
      2.49 g
      Cedevolezza meccanica della sospensione (Cms)
      850 μm/N
      Superficie del cono (Sd)
      27.3 cm²
      Prodotto BL (BL)
      2.97 Tm
      Volume equivalente di cedevolezza (Vas)
      0.99 L
      Escursione lineare massima (Xmax)
      5.4 mm
      Materiale del cono / diaframma
      Aluminum
      Materiale della sospensione
      Rubber
      Materiale del cestello / telaio
      Polymer
      Materiale del magnete
      Neodymium
      Diametro esterno complessivo
      78 x 78 mm
      Profondità complessiva
      51 mm
      Diametro del ritaglio del pannello frontale
      73 mm
      Diametro del cerchio dei fori di montaggio
      83 mm
      # Numero di fori di montaggio
      4
      Diametro dei fori di montaggio
      4.20 mm

      Show more
