      TiCW 638Nd Woofer Medio-Bassi

      Morel TiCW 638Nd Woofer Medio-Bassi

      €349,95

      2 In magazzino

      Aggiungi al carrello

      Morel TiCW 638Nd Woofer Medio-Bassi

      2 reviews
      5 da 5
      2 reviews
      5 stars
      100%
      4 stars
      0%
      3 stars
      0%
      2 stars
      0%
      1 stella
      0%
      Leggi le recensioni
      Marchio: Morel
      Mostra tutti Woofer medio-bassi
      6" | 8 Ω
      TiCW 638Nd Woofer Medio-Bassi
      TiCW 638Nd Woofer Medio-Bassi
      TiCW 638Nd Woofer Medio-Bassi
      TiCW 638Nd Woofer Medio-Bassi
      TiCW 638Nd Woofer Medio-Bassi
      TiCW 638Nd Woofer Medio-Bassi
      € 289,21€ 349,95 2 In magazzino
      • -5% Acquista 4 per soli € 332,45 per pezzo
      +-
      Aggiungi al carrello

      Buy now, pay later

      • Spedizione gratuita a partire da € 199
      • Ordinato ora, spedito lunedì
      • Minimo due anni di garanzia
      • Periodo di recesso di 45 giorni per i resi
      • Dicono di noi:
      Richiedi preventivo
      Hai una domanda su questo prodotto?

      Hai una domanda su questo prodotto?

      Il nostro addetto è lieto di aiutarvi a trovare il prodotto giusto

      TiCW 638Nd Woofer Medio-Bassi
      TiCW 638Nd Woofer Medio-Bassi
      TiCW 638Nd Woofer Medio-Bassi
      TiCW 638Nd Woofer Medio-Bassi
      TiCW 638Nd Woofer Medio-Bassi
      TiCW 638Nd Woofer Medio-Bassi

      Descrizione del prodotto Morel TiCW 638Nd Woofer Medio-Bassi

      For serious speaker builders that demand the world's best drivers, look no further than Morel's Titanium Advanced woofer series. The 6" TiCW 638Nd features a Coppersleeve Neolin motor and a titanium bobbin for ultra-quick transient response and a Uniflow chassis for reduced power compression.



      Highlights

      • Open Uniflow aluminum diecast chassis for reduced reflections
      • Hybrid neodymium/ferrite magnet ferrite system
      • Titanium coil bobbin for low energy storage
      • 3" Hexatech aluminum voice coil
      • High 1,000W instantaneous power handling
      • Coppersleeve Neolin motor



      Product details

      Morel TiCW 638Nd Titanium Series Hybrid Cu 6" Woofer 8 Ohm



      Since 1975, Morel has been on an ever-evolving quest to create the perfect, ultimate loudspeaker. This dedication is apparent in every product they produce: tweeters, midranges, woofers, and finished systems that serve the Hi-Fi, home theater, and car audio markets. Morel systems are today sold in more than 55 countries around the globe. Their products are made with exceptional care; each is assembled by hand and extensively tested, undergoing seven different quality assurance steps, to ensure only the highest standards are met.



      Morel Titanium Advanced Series

      The Titanium Advanced woofer series from Morel is the latest leap forward in woofer design. Huge 3" Hexatech™ aluminum voice coils (that use hexagonal shaped wire for high sensitivity and power handling) are wound onto titanium bobbins for amazingly low energy storage, resulting in lightning quick transients for superior attack and decay transients. Qms is also raised and allows for a wider range of enclosure options. Three magnetic systems are available: dual ferrite, Hybrid™ neodymium/ferrite, and Hybrid™ neodymium/ferrite with a Coppersleeve Neolin™ motor. Each is available in 4 and 8 ohm impedance.



      Uniflow­™ Aluminum Diecast Chassis

      All of this wouldn't mean anything if the air swept by the driver got trapped in the motor or frame. Morel designed the Uniflow chassis to be as open and sonically transparent as possible. An over-sized vent on the pole piece, a frame-suspended spider, and exposed voice coil combine to virtually eliminate reflections and output-robbing power compression. The Uniflow chassis also allows for the use of an over-sized spider for complete control of the over-sized voice coil.



      The 6" TiCW 638Nd woofer features a Hybrid neodymium/ferrite magnet system, Coppersleeve Neolin motor (for the best possible transient response), 4-ohm impedance, and a unique, one-piece DPC (Damped Polymer Composite) cone that offers flat frequency response from 40 Hz to 4,500 Hz on-axis, and from 40 Hz to 4,000 Hz off-axis. Its large voice coil allows it to handle 10 ms peak power transients of up to 1,000 watts when used correctly.

      Show more

      Specifiche

      Numero dell'articolo:
      TiCW 638Nd
      EAN
      0848864001999
      Serie del woofer
      Morel Titanium Former series
      Tipo di woofer
      Midwoofer
      Diametro nominale
      6"
      Gestione della potenza (RMS)
      150 Watts
      Gestione della potenza (max)
      1000 Watts
      Impedenza (Z)
      8 ohms
      Sensibilità (SPL a 1m / 2,83V)
      87 dB
      Risposta in frequenza
      40 to 4,500 Hz
      Diametro della bobina mobile
      3"
      Resistenza DC (Re)
      5.4 ohms
      Induttanza della bobina mobile (Le)
      0.32 mH
      Frequenza di risonanza (Fs)
      33 Hz
      Fattore di merito meccanico (Qms)
      2.47
      Fattore di merito elettromagnetico (Qes)
      0.32
      Fattore di merito totale (Qts)
      0.29
      Massa del diaframma incl. la massa dell'aria (Mms)
      16.8g
      Cedevolezza meccanica della sospensione (Cms)
      1.46 mm/N
      Superficie del cono (Sd)
      119 cm²
      Prodotto BL (BL)
      7.5 Tm
      Volume equivalente di cedevolezza (Vas)
      1.02 ft.³
      Escursione lineare massima (Xmax)
      5.25 mm
      Materiale del cono / diaframma
      Poly Composite
      Materiale della sospensione
      Rubber
      Materiale del filo della bobina mobile
      Aluminum
      Supporto della bobina mobile
      Titanium
      Materiale del cestello / telaio
      Cast Aluminum
      Materiale del magnete
      Neodymium
      Diametro esterno complessivo
      6.3"
      Profondità complessiva
      2.72"
      Diametro del ritaglio del pannello frontale
      5.51"
      # Numero di fori di montaggio
      6
      Diametro dei fori di montaggio
      4.2 mm
      Volume per cassa sigillata
      0.14 ft.³
      Frequenza di risonanza della cassa sigillata (F3)
      93 Hz
      Volume per cassa reflex
      0.28 ft.³
      Frequenza di risonanza della cassa reflex (F3)
      59 Hz

      Show more

      Recensioni

      2 reviews
      Recensisci questo prodotto
      5 di 5
      Super, fast delivery.
      Da David Drimal on 12 Marzo 2024
      5 di 5
      Improvement from standard TiW series. Open, rich and smooth sound at the same time. Very satisfactory loudspeaker, highly recommended. Used as a midrange in a three way system, with Fc 270 Hz and 3 kHz.Woofers Wavecor SW215 WA01(x2) and Morel ST1108 tweeter. If you don't have a measurement set be aware, because the frequency response and parameters are not the same as datasheet claims.
      Da Vittorio on 10 Marzo 2022
