      PLUVIA-7HD Chrome Woofer a Gamma Completa

      Markaudio PLUVIA-7HD Chrome Woofer a Gamma Completa

      €52,45

      10+ Arrivo previsto il 16-01-2026

      Markaudio PLUVIA-7HD Chrome Woofer a Gamma Completa

      6 reviews
      5 da 5
      6 reviews
      5 stars
      83%
      4 stars
      17%
      3 stars
      0%
      2 stars
      0%
      1 stella
      0%
      Leggi le recensioni
      Marchio: Markaudio
      € 43,35€ 52,45 Esaurito10+ Arrivo previsto il 16-01-2026
      • -5% Acquista 4 per soli € 49,83 per pezzo

      Buy now, pay later

      • Spedizione gratuita a partire da € 199
      • Presto di nuovo disponibile
      • Minimo due anni di garanzia
      • Periodo di recesso di 45 giorni per i resi
      • Dicono di noi:
      Richiedi preventivo
      Hai una domanda su questo prodotto?

      Hai una domanda su questo prodotto?

      Il nostro addetto è lieto di aiutarvi a trovare il prodotto giusto

      Descrizione del prodotto Markaudio PLUVIA-7HD Chrome Woofer a Gamma Completa

      The second-generation Pluvia 7HD is designed to supersede our original Alpair 7 series drive units. It employs many of the same components, and has a very similar balance of frequency response and Thiele / Small values to the old Alpair model, packaged in the more efficient and convenient Pluvia frame.



      Highlights

      • Vintage Gold 4’’ magnesium alloy cone
      • Operating range to 30KHz - very linear response
      • Very shallow multiform cone profile – very broad directivity pattern
      • Advanced low-distortion motor design
      • Long-stroke suspension with arrestor and progressive-rate spider
      • Low-profile surface-mount reinforced polymer basket



      Product details

      Markaudio Pluvia 7 HD Chrome Full-range Woofer



      The second-generation Pluvia 7HD is designed to supersede our original Alpair 7 series drive units. It employs many of the same components and has a very similar balance of frequency response and Thiele / Small values to the old Alpair model, packaged in the more efficient and convenient Pluvia frame. With a mounting depth of less than 4mm, the Pluvia may be surface or flush-mounted, and the design of the mounting legs is very open, allowing good airflow to the rear.



      The low-mass coil, suspension, and shallow-profile cone are highly efficient. Frequency response extends beyond 30KHz, and the generous 4mm (1-way) Xmax and conveniently balanced T/S parameters allow 40Hz bass output in suitable enclosure designs. The sound character is neutral and highly detailed, with excellent off-axis performance. It is an extremely flexible drive unit for music, small HT and commercial AV applications, and offers exceptional performance at an affordable price point.

      Show more

      Specifiche

      Numero dell'articolo:
      PLUVIA-7HD Chrome
      EAN
      0691046947758
      Serie del woofer
      Markaudio Pluvia series
      Tipo di woofer
      Full-Range Woofer
      Diametro nominale
      4''
      Gestione della potenza (RMS)
      20 Watts
      Impedenza (Z)
      8 Ohms
      Sensibilità (SPL a 1m / 2,83V)
      85.74 dB
      Risposta in frequenza
      20 - 40,000 Hz
      Resistenza DC (Re)
      5.4000 Ohms
      Induttanza della bobina mobile (Le)
      0.1652 mH
      Frequenza di risonanza (Fs)
      72.5 Hz
      Fattore di merito meccanico (Qms)
      3.1446
      Fattore di merito elettromagnetico (Qes)
      0.7173
      Fattore di merito totale (Qts)
      0.584
      Massa del diaframma incl. la massa dell'aria (Mms)
      3.8390 g
      Massa in movimento del diaframma (Mmd)
      3.6373 g
      Cedevolezza meccanica della sospensione (Cms)
      1.2536 mm/N
      Superficie del cono (Sd)
      0.0050 m2
      Prodotto BL (BL)
      3.6297
      Volume equivalente di cedevolezza (Vas)
      4.4227 L
      Escursione lineare massima (Xmax)
      4 mm
      Materiale del cono / diaframma
      Magnesium alloy
      Materiale della sospensione
      Rubber
      Materiale del cestello / telaio
      Polymer
      Materiale del magnete
      Ferrite
      Diametro esterno complessivo
      122.3 mm
      Profondità complessiva
      71.5 mm
      Diametro del ritaglio del pannello frontale
      100 mm
      Diametro del cerchio dei fori di montaggio
      112 mm
      # Numero di fori di montaggio
      5
      Diametro dei fori di montaggio
      5 - 3.1 mm

      Show more

      5 di 5
      I bought 2 for my stereo player/radio diy project. These speakers are exactly what their specs are saying. Thru all frequencies they produce a very pleasant, no distortion or harshness sound. From the deep base of Pink Floyd to the softness of George Benson's guitar it is total enjoyment of the music. I never listen too loud, but they can be very loud.
      Da Sergiy Pylypenko on 13 Settembre 2025
      5 di 5
      Fast delivery, well packed. excellent online shop!
      Da Peter on 17 Luglio 2025
