      Descrizione del prodotto Dayton Audio KABT-250 Amplifier Board

      The Dayton Audio KABT-250 is a compact, Bluetooth 5.0 stereo amplifier board delivering up to 2 x 50W or 1 x 100W in mono mode. Featuring aptX support, gain control, DSP expandability, and battery compatibility, it's ideal for wireless speaker builds and custom audio applications.



      Highlights of the Dayton Audio KABT-250 Amplifier Board

      • 2 x 50W stereo or 1 x 100W mono output with efficient Class D design
      • Bluetooth 5.0 with aptX and TWS (True Wireless Stereo) support
      • DSP-ready via PC UI socket for KPX programmer
      • Versatile power options including 12–24V DC and external battery input



      Product details Dayton Audio KABT-250 Amplifier Board

      Dayton Audio KABT-250 stereo Bluetooth amplifier module



      The Dayton Audio KABT-250 amplifier board is a feature-rich solution for DIY wireless audio systems, portable speakers, and embedded smart devices. Powered by a high-efficiency Class D amplifier, it delivers 50 watts per channel in stereo mode or 100 watts in mono bridged mode. With Bluetooth 5.0 and aptX support, users enjoy high-quality, low-latency wireless streaming, while True Wireless Stereo (TWS) capability allows pairing two boards for full stereo separation.

      The board features a 12–24 VDC input or can be powered by an external battery (note: it does not include charging functionality). Inputs include 3.5 mm AUX and external line-in, while outputs are configured via onboard headers for flexible wiring. Additional features include gain switching (20 dB or 26 dB), external volume and Bluetooth pairing support, and a PC UI socket for DSP programming via the optional KPX module.

      Designed for hobbyists, makers, and integrators, the KABT-250 combines robust audio performance with deep customization potential in a compact, modular form factor.

      Show more

      Specifiche

      Numero dell'articolo:
      KABT-250
      EAN
      0848791010910
      Potenza di uscita nominale
      2 x 50W @ 4Ω, 1 x 100W @ 2Ω
      Carico minimo
      2 ohms in mono mode
      Rapporto segnale/rumore (SNR)
      92 dB
      Distorsione
      0.02% @ 8 ohms, 10W, 1 kHz
      Risposta in frequenza
      22 to 22,000 Hz (±3 dB)
      Impedenza di ingresso
      4-8 ohms
      Tipo di connessione di ingresso
      3.5 mm AUX and external line-in
      Funzione DSP
      Bluetooth
      Requisiti di alimentazione
      12 to 24 VDC, 4A
      Dimensioni (L x P x H)
      9.1x6.8x1.7 cm
      Distanza tra i fori di montaggio
      84 x 61 mm
      Diametro del foro di montaggio
      3.5 mm

      Show more

      Recensioni

      1 reviews
      Recensisci questo prodotto
      3 di 5
      Ik gebruik de goedkopere variant van Sure Electronics. Visueel identiek, behalve de kleur van het printplaatje. Ik vraag me af wat de meerprijs van de Dayton Audio verantwoordt. De Sure heeft zich voor mij bewezen. Ik gebruik hem in een 2.1, 2*50 Watt voor de tops, 1*100 Watt voor de sub.
