      12-212/C8/62 HEX Subwoofer

      ETON 12-212/C8/62 HEX Subwoofer

      €439,95

      1 In magazzino

      Aggiungi al carrello

      ETON 12-212/C8/62 HEX Subwoofer

      4 reviews
      5 da 5
      4 reviews
      5 stars
      100%
      4 stars
      0%
      3 stars
      0%
      2 stars
      0%
      1 stella
      0%
      Leggi le recensioni
      Marchio: ETON
      Mostra tutti Subwoofer
      12'' | 8 Ω
      12-212/C8/62 HEX Subwoofer
      12-212/C8/62 HEX Subwoofer
      12-212/C8/62 HEX Subwoofer
      12-212/C8/62 HEX Subwoofer
      12-212/C8/62 HEX Subwoofer
      12-212/C8/62 HEX Subwoofer
      12-212/C8/62 HEX Subwoofer
      12-212/C8/62 HEX Subwoofer
      € 363,60€ 439,95 1 In magazzino
      • -5% Acquista 4 per soli € 417,95 per pezzo
      +-
      Aggiungi al carrello

      Buy now, pay later

      • Spedizione gratuita a partire da € 199
      • Ordinato ora, spedito lunedì
      • Minimo due anni di garanzia
      • Periodo di recesso di 45 giorni per i resi
      • Dicono di noi:
      Richiedi preventivo
      Hai una domanda su questo prodotto?

      Hai una domanda su questo prodotto?

      Il nostro addetto è lieto di aiutarvi a trovare il prodotto giusto

      12-212/C8/62 HEX Subwoofer
      12-212/C8/62 HEX Subwoofer
      12-212/C8/62 HEX Subwoofer
      12-212/C8/62 HEX Subwoofer
      12-212/C8/62 HEX Subwoofer
      12-212/C8/62 HEX Subwoofer
      12-212/C8/62 HEX Subwoofer
      12-212/C8/62 HEX Subwoofer

      Vantaggi e svantaggi

      Secondo i nostri esperti
      • Low resonance frequency of 23–24 Hz ideal for subwoofer use

      Descrizione del prodotto ETON 12-212/C8/62 HEX Subwoofer

      High-performance 12" subwoofer driver engineered for precision and power. The SYMPHONY II 12-212/C8/62 HEX delivers deep bass extension, high sensitivity, and robust build quality, making it ideal for high-end audio systems and demanding DIY loudspeaker applications.



      Highlights of the SYMPHONY II 12-212/C8/62 HEX

      • Robust ferrite magnet and overhung motor system for tight low-frequency control
      • Exceptional Xmax of ±8.5 mm (electrical) and ±15.7 mm (mechanical) for high excursion and output
      • Low resonance frequency of 23–24 Hz ideal for subwoofer use
      • 92 dB sensitivity and 200 W rated power handling for impactful performance



      Product details SYMPHONY II 12-212/C8/62 HEX

      SYMPHONY II 12-212/C8/62 HEX Subwoofer Driver



      The SYMPHONY II 12-212/C8/62 HEX is a premium 12" subwoofer optimized for deep, controlled bass reproduction in both sealed and vented enclosures. It features a powerful ferrite magnet with a 1.00 T flux density and an overhung motor structure, ensuring high linearity and low distortion even at elevated excursion levels. The driver achieves a remarkable Xmax of ±8.5 mm electrically and ±15.7 mm mechanically, supported by a Kapton former and dual-layer copper voice coil. With a nominal impedance of 8 Ω and a DC resistance of 6.2 Ω, it integrates well with most amplification setups. Offering a low resonance frequency of 23–24 Hz and a broad recommended frequency range of 25 – 500 Hz, it’s well-suited for subwoofer and low-mid applications in high-end audio systems. The total moving mass of 92.7 g and a suspension compliance of 0.47 mm/N enable accurate transient response. Mechanical and electrical Q values of 7.15 (Qms) and 0.32 (Qes), along with a total Q of 0.31 (Qts), support flexible enclosure tuning. The driver has an effective piston area of 515 cm² and a rated sensitivity of 92 dB SPL (1W/1m), delivering powerful sound output. With a solid overall diameter of 330.5 mm and a cutout diameter of 282 mm, the 12-212/C8/62 HEX is ready to be the foundation of your next serious low-frequency project. Crafted in Germany, it meets IEC 60268-5 standards and weighs 6.3 kg, reflecting its professional-grade construction.

      Show more

      Specifiche

      Numero dell'articolo:
      12-212/C8/62 HEX
      EAN
      8785256846795
      Serie del woofer
      Symphony II
      Tipo di woofer
      Subwoofer
      Diametro nominale
      12 "
      Gestione della potenza (RMS)
      200 Watts
      Gestione della potenza (max)
      400 Watts
      Impedenza (Z)
      8 Ω
      Sensibilità (SPL a 1m / 2,83V)
      92 dB
      Risposta in frequenza
      24 - 1.000 Hz
      Diametro della bobina mobile
      62 mm
      Resistenza DC (Re)
      6.2 Ω
      Induttanza della bobina mobile (Le)
      1.57 mH
      Frequenza di risonanza (Fs)
      24 Hz
      Fattore di merito meccanico (Qms)
      7.15
      Fattore di merito elettromagnetico (Qes)
      0.32
      Fattore di merito totale (Qts)
      0.31
      Massa del diaframma incl. la massa dell'aria (Mms)
      92.7 g
      Massa in movimento del diaframma (Mmd)
      92.7 g
      Cedevolezza meccanica della sospensione (Cms)
      0.47 mm/N
      Superficie del cono (Sd)
      515 cm²
      Prodotto BL (BL)
      15.7 Tm
      Volume equivalente di cedevolezza (Vas)
      176 Liters
      Escursione lineare massima (Xmax)
      +/- 8.5 mm
      Perdite meccaniche del driver (Rms)
      2.13 kg/s
      Materiale del filo della bobina mobile
      Copper
      Supporto della bobina mobile
      Kapton
      Materiale del magnete
      Ferrite
      Diametro esterno complessivo
      330.5 mm
      Profondità complessiva
      150 mm
      Diametro del ritaglio del pannello frontale
      282 mm
      # Numero di fori di montaggio
      8
      Diametro dei fori di montaggio
      6.5 mm

      Show more
