      PTMini-6 Tweeter Planare

      Dayton Audio PTMini-6 Tweeter Planare

      €14,95

      10+ In magazzino

      Aggiungi al carrello

      Dayton Audio PTMini-6 Tweeter Planare

      27 klantbeoordelingen
      5 da 5
      27 klantbeoordelingen
      5 stars
      81%
      4 stars
      11%
      3 stars
      4%
      2 stars
      4%
      1 stella
      0%
      Leggi le recensioni
      Marchio: Dayton Audio
      Planar | 6 Ω
      PTMini-6 Tweeter Planare
      PTMini-6 Tweeter Planare
      PTMini-6 Tweeter Planare
      PTMini-6 Tweeter Planare
      PTMini-6 Tweeter Planare
      PTMini-6 Tweeter Planare
      PTMini-6 Tweeter Planare
      PTMini-6 Tweeter Planare
      PTMini-6 Tweeter Planare
      PTMini-6 Tweeter Planare
      PTMini-6 Tweeter Planare
      PTMini-6 Tweeter Planare
      € 12,36€ 14,95 10+ In magazzino
      • -5% Acquista 4 per soli € 14,20 per pezzo
      € 14,95
      +-
      Aggiungi al carrello
      🔒 Pagamento sicuro
      MastercardVisaPostepayBank TransferApple PayGoogle Paypaypal

      Buy now, pay later

      • Spedizione gratuita a partire da € 199
      • Ordinato ora, spedito domani
      • Minimo cinque anni di garanzia
      • Periodo di recesso di 45 giorni per i resi
      • Dicono di noi:
      Richiedi preventivo
      Hai una domanda su questo prodotto?

      Hai una domanda su questo prodotto?

      Il nostro addetto è lieto di aiutarvi a trovare il prodotto giusto

      PTMini-6 Tweeter Planare
      PTMini-6 Tweeter Planare
      PTMini-6 Tweeter Planare
      PTMini-6 Tweeter Planare
      PTMini-6 Tweeter Planare
      PTMini-6 Tweeter Planare
      PTMini-6 Tweeter Planare
      PTMini-6 Tweeter Planare
      PTMini-6 Tweeter Planare
      PTMini-6 Tweeter Planare
      PTMini-6 Tweeter Planare
      PTMini-6 Tweeter Planare

      Vantaggi e svantaggi

      Secondo i nostri esperti
      • High output and exceptional treble definition

      Descrizione del prodotto Dayton Audio PTMini-6 Tweeter Planare

      The Dayton Audio PTMini-6 is a miniature planar tweeter that is big on performance and sound quality! With 6 ohm impedance and incredibly small size this is an excellent choice for car audio or home use.



      Highlights of the Dayton Audio PTMini-6 Planar Tweeter

      • Compact planar ribbon tweeter driver
      • High output and exceptional treble definition
      • Surface or flush mount installation
      • Potent neodymium magnetic design
      • Supports 4,000 Hz crossover, 12 dB/octave



      Product details Dayton Audio PTMini-6 Planar Tweeter

      Dayton Audio PTMini-6 Planar Tweeter 6 Ohm



      The clarity, definition, and transparency of a planar tweeter is unmatched by almost any other type of tweeter. Now Dayton Audio lets you build planar technology into more compact projects with the PTMini-6 planar tweeter! The surface-mount housing design can also be flush-mounted for a world of possible uses, such as a car A-pillar tweeter, a supertweeter for a full-range driver, a rear-mounted ambience tweeter, a conventional forward-facing tweeter configuration, or even a line array!



      The membrane of a planar tweeter is an almost weightless ribbon of heat-resistant Kapton material and an etched aluminum conductor, enabling the performance of aluminum ribbon tweeters without the losses inherent in the transformer of a conventional ribbon tweeter. The result is a tweeter that is incredibly fast, dynamic, and smooth sounding with imperceptible distortion and excellent power handling. A crossover cut-off frequency of 4,000 Hz or higher is recommended with a 12 dB/octave filter slope.



      FAQ about the Dayton Audio PTMini-6 Planar Tweeter

      What is the impedance of the PTMini-6?

      The Dayton Audio PTMini-6 typically has a nominal impedance of 6 ohms



      What are the characteristics of a planar tweeter?

      Planar tweeters have distinct characteristics that set them apart from conventional dome tweeters. Unlike dome tweeters, which use a small, domed diaphragm, planar tweeters feature a flat diaphragm, usually a very thin and lightweight film which also has responds quickly to high-frequency signals. Planar tweeters generally provide a broad and even sound dispersion and they are favored for their smooth, non-fatiguing sound. These characteristics make planar tweeters highly prized in high-end audio systems.

      Show more

      Specifiche

      Numero dell'articolo:
      PTMini-6
      EAN
      0848791001680
      Tipo di tweeter
      Planar ribbon tweeter
      Serie del tweeter
      Planar Series
      Gestione della potenza (RMS)
      15 Watts
      Impedenza (Z)
      6 Ω
      Sensibilità (SPL a 1m / 2,83V)
      91.5 dB
      Risposta in frequenza
      2,900 to 25,000 Hz
      Frequenza di risonanza (Fs)
      4461 Hz
      Resistenza DC (Re)
      5.90 Ω
      Fattore di merito totale (Qts)
      1.74
      Diametro esterno complessivo
      3.27" x 0.91" (83+10.5 x 8.2 mm)
      Diametro del ritaglio
      Element: 2.375" x 0.375"
      Profondità
      0.32"
      Tipo di montaggio
      Screws

      Show more

      Recensioni

      27 klantbeoordelingen
      Recensisci questo prodotto
      5 di 5
      Der kleine HT ist für ein preiswertes und leicht zu bauendes DIY Projekt mehr ausreichend. Als SHT für einen BB sehr schön und leicht ankoppelbar über einen 1µF MKP. Für Zimmerlautstärke hervorragend geeignet. Der Bauvorschlag wird dazu veröffentlicht.
      Da Kay on 25 Agosto 2026
      2 di 5
      Er spielt doch wesentlich leiser als die Angaben vermuten lassen
      Da Michael on 24 Giugno 2026
