Name: Dayton Audio DMA105-4 Woofer Medio-Bassi
Brand: Dayton Audio
SKU: DMA105-4
Price: 31.95 EUR
Availability: InStock
Rating: 4.65 (3 reviews)

4" | 4 Ω

€ 26,41€ 31,95 7 In magazzino

Spedizione gratuita a partire da € 199
Ordinato ora, spedito lunedì
Minimo cinque anni di garanzia
Periodo di recesso di 45 giorni per i resi

Dicono di noi:

Confronta

Richiedi preventivo

Hai una domanda su questo prodotto?

Il nostro addetto è lieto di aiutarvi a trovare il prodotto giusto

Descrizione del prodotto Dayton Audio DMA105-4 Woofer Medio-Bassi

Dayton Audio's DMA105-4 4" high performance full-range driver combines a rigid aluminum cone, powerful dual magnet neodymium motor, and a proprietary open frame to create a state of the art speaker that delivers low distortion, natural response, and amazing high frequency capability. Make the DMA105-4 the first choice for your next smart speaker, portable Bluetooth speaker, or even high output line array design.

Highlights

Excellent high frequency response for true full-range applications
Dual neodymium motor to create a symmetrical magnetic field for superb control
Large copper cap lowers distortion while improving high frequency response
Vented aluminum voice coil former with exceptional heat dissipation for high power handling
Exclusive 8-spoke open frame design provides extensive venting and minimal reflection
DIY friendly, oversized mounting flange makes installation simple
Matching tunable passive radiators also available!

Product details

Dayton Audio DMA105-4 4" Dual Magnet Aluminum Cone Full-Range Driver 4 Ohm

Providing high efficiency with low distortion, Dayton Audio's DMA105-4 4" aluminum cone full-range is an ideal driver for use in many of today's modern speaker designs. Whether you are designing a portable Bluetooth speaker, sound bar, compact desktop speaker, or even a high output line array the DMA105-4 is the perfect full-range for the job.

Designed for the highest performance while delivering maximum value, the no compromise design of the DMA105-4 produces true full-range output capability with minimal distortion. The motor uses dual neodymium magnets creating a strong and symmetrical magnetic field providing high efficiency with excellent cone control. The magnet assembly also includes a large copper cap and sleeve to lower inductance and distortion resulting in improved high frequency response. The 2-layer 1" voice coil is wound on a vented aluminum former providing excellent heat dissipation for high power handling and low power compression. A rubber surround and large spider keeps the lightweight aluminum cone linear with superb mechanical damping. In addition, the aluminum dust cap is attached directly to the voice coil former to improve high frequency response with terrific off axis performance. Holding everything together is a proprietary 12-spoke frame with an extremely open design that has extensive venting under the spider and ample room for high excursion.

Furthermore, Dayton Audio designed the frame for all the DMA Series with DIY speaker builders in mind. The oversized mounting flange means that no precision cutouts are necessary. To ensure an easy installation, the terminals are oriented in such a way that no odd cutouts or notches are needed for connector or wire clearance. Finally, the corners have a 1/8" radius, meaning that for flush mounting you can get a perfect fit using any standard 1/4" straight cut router bit.

Recensioni

3 reviews

Recensisci questo prodotto

5 di 5

Bought pair of these for three way BT speaker project. Handling them in my paws didn't exactly convince me - these are quite platicky, and when mounted by just four screws, the basket ("front flange") arcs a bit due to the foam isolation compression. Playing them open air looked like they will go over excutsion, but upon proper installation with eight screws (four supporting to mitigate the arcing), I am very surprised with how potent and strong ...

Da Petr B. on 3 Settembre 2023

Все чудово

Da Oleksandr on 7 Ottobre 2022
