      Descrizione del prodotto Dayton Audio CE40P-8 Micro Altoparlante

      Dayton Audio’s CE40P-8 is an economical small full-range driver that features a high-output neodymium motor, a lightweight paper cone, a front gasket, and a steel frame with two mounting lobes. 8 ohm impedance.



      Highlights

      • Paper cone with mylar dust cap for extended highs
      • Rugged stamped steel frame
      • High-energy double neodymium magnet motor



      Product details

      Dayton Audio CE Series CE40P-8 1-1/2" Mini Speaker

      Dayton Audio is pleased to introduce the new Commercial Engineering (CE) Series of small loudspeaker drivers. Engineers, designers, and integrators will benefit from how effortlessly these speaker components satisfy the diverse demands associated with consumer electronics and audio-enabled projects.

      Multiple types and styles are available within the CE Series driver family. Each was produced to provide excellent audio quality no matter what the overall system design goals may be, and to suit a wide spectrum of engineering requirements. These versatile yet economical loudspeakers are available in sizes from 28 mm (1-1/8") to 90 mm (3-1/2") in diameter, and with power ratings from 1.5 watts to 5 watts continuous RMS power.

      The CE40P-8 provides features you’d expect from a much larger driver, in a size that’s perfect for miniature applications that require wide dispersion and rich, natural sound. Its high-quality design features a paper cone with mylar dust cap, rubber surround, textile spider, high-performance neodymium motor, and a steel frame with dual mounting lobes for conventional mounting.

      Show more

      Specifiche

      Numero dell'articolo:
      CE40P-8
      EAN
      0848791000379
      Serie del woofer
      Dayton Audio CE series
      Tipo di woofer
      Full-range
      Diametro nominale
      1-1/2"
      Gestione della potenza (RMS)
      2 Watts
      Gestione della potenza (max)
      4 Watts
      Impedenza (Z)
      8 ohms
      Sensibilità (SPL a 1m / 2,83V)
      83 dB
      Risposta in frequenza
      200 to 20,000 Hz
      Diametro della bobina mobile
      0.51"
      Resistenza DC (Re)
      7.3 ohms
      Induttanza della bobina mobile (Le)
      0.25 mH
      Frequenza di risonanza (Fs)
      227 Hz
      Fattore di merito meccanico (Qms)
      4.19
      Fattore di merito elettromagnetico (Qes)
      1.63
      Fattore di merito totale (Qts)
      1.17
      Massa del diaframma incl. la massa dell'aria (Mms)
      0.6g
      Cedevolezza meccanica della sospensione (Cms)
      0.225 mm/N
      Superficie del cono (Sd)
      6.76 cm²
      Prodotto BL (BL)
      1.53 Tm
      Escursione lineare massima (Xmax)
      1.2 mm
      Materiale del cono / diaframma
      Paper
      Materiale della sospensione
      Cloth
      Materiale del magnete
      Neodymium
      Diametro esterno complessivo
      1.57"
      Profondità complessiva
      0.9"
      Diametro del ritaglio del pannello frontale
      1.41"
