      14MC700Nd Bass-midwoofer

      Beyma 14MC700Nd Bass-midwoofer

      €289,95

      6 In magazzino

      Aggiungi al carrello

      Beyma 14MC700Nd Bass-midwoofer

      0 klantbeoordelingen
      0 da 5
      0 klantbeoordelingen
      5 stars
      0%
      4 stars
      0%
      3 stars
      0%
      2 stars
      0%
      1 stella
      0%
      Leggi le recensioni
      Marchio: Beyma
      14" | 8 Ω
      14MC700Nd Bass-midwoofer
      14MC700Nd Bass-midwoofer
      14MC700Nd Bass-midwoofer
      14MC700Nd Bass-midwoofer
      14MC700Nd Bass-midwoofer
      14MC700Nd Bass-midwoofer
      14MC700Nd Bass-midwoofer
      14MC700Nd Bass-midwoofer
      14MC700Nd Bass-midwoofer
      14MC700Nd Bass-midwoofer
      14MC700Nd Bass-midwoofer
      14MC700Nd Bass-midwoofer
      14MC700Nd Bass-midwoofer
      14MC700Nd Bass-midwoofer
      14MC700Nd Bass-midwoofer
      € 239,63€ 289,95 6 In magazzino
      • -5% Acquista 4 per soli € 275,45 per pezzo
      € 289,95
      +-
      Aggiungi al carrello
      🔒 Pagamento sicuro
      MastercardVisaPostepayBank TransferApple PayGoogle Paypaypal

      Buy now, pay later

      • Spedizione gratuita a partire da € 199
      • Ordinato ora, spedito oggi
      • Minimo due anni di garanzia
      • Periodo di recesso di 45 giorni per i resi
      • Dicono di noi:
      Richiedi preventivo
      Hai una domanda su questo prodotto?

      Hai una domanda su questo prodotto?

      Il nostro addetto è lieto di aiutarvi a trovare il prodotto giusto

      14MC700Nd Bass-midwoofer
      14MC700Nd Bass-midwoofer
      14MC700Nd Bass-midwoofer
      14MC700Nd Bass-midwoofer
      14MC700Nd Bass-midwoofer
      14MC700Nd Bass-midwoofer
      14MC700Nd Bass-midwoofer
      14MC700Nd Bass-midwoofer
      14MC700Nd Bass-midwoofer
      14MC700Nd Bass-midwoofer
      14MC700Nd Bass-midwoofer
      14MC700Nd Bass-midwoofer
      14MC700Nd Bass-midwoofer
      14MC700Nd Bass-midwoofer
      14MC700Nd Bass-midwoofer
      14MC700Nd Bass-midwoofer
      14MC700Nd Bass-midwoofer
      14MC700Nd Bass-midwoofer

      Vantaggi e svantaggi

      Secondo i nostri esperti
      • Waterproof cone with treatment for both sides
      • Optimized for bass or mid-bass high performance audio systems

      Descrizione del prodotto Beyma 14MC700Nd Bass-midwoofer

      The Beyma 14MC700Nd is a powerful and lightweight 14” transducer built for precise low and mid-frequency performance. Equipped with a 3” DUO voice coil and neodymium magnet, it delivers high output with low power compression, making it ideal for high-performance audio systems.



      Highlights of the Beyma 14MC700Nd

      • 700 W AES / 1,400 W program power with 99 dB sensitivity
      • 3” DUO double-layer copper in/out voice coil with Malt Cross® cooling
      • Waterproof cone and neodymium magnetic structure for reliable outdoor use
      • Lightweight build with 4 kg net weight and compact 166 mm depth



      Product details Beyma 14MC700Nd

      Beyma 14MC700Nd Low & Mid Frequency Transducer



      The Beyma 14MC700Nd is a 14-inch low and mid-frequency transducer from the MC Series, tailored for professional audio systems requiring a high-efficiency and lightweight solution. Featuring a 3” DUO double-layer in/out copper voice coil and neodymium motor structure, it offers a remarkable sensitivity of 99 dB (1W/1m) and power handling of 700 W AES (1,400 W program). It integrates Beyma’s exclusive Malt Cross® Cooling System, which ensures reduced power compression and excellent thermal management during prolonged operation. The waterproof-treated cone and aluminum demodulating ring contribute to its durability and distortion reduction, making it suitable for both indoor and outdoor applications. With a resonant frequency of 51 Hz, an extended Xmax of ±7 mm, and a recommended bass-reflex enclosure volume of 55 liters (Fb = 60 Hz), the 14MC700Nd provides controlled excursion and optimized low-frequency behavior. The total weight of only 4 kg and shallow mounting depth (166 mm) allow easy integration into high-performance, compact loudspeaker enclosures.

      Show more

      Specifiche

      Numero dell'articolo:
      14MC700Nd
      EAN
      8435469043428
      Tipo di woofer
      Low and Mid Frequency Transducer
      Diametro nominale
      14"
      Gestione della potenza (RMS)
      700 Watt
      Potenza continua del programma
      1400 Watt
      Impedenza (Z)
      8 Ω
      Sensibilità (SPL a 1m / 2,83V)
      99 dB
      Risposta in frequenza
      55 - 4000 Hz
      Diametro della bobina mobile
      76 mm
      Resistenza DC (Re)
      5.3 Ω
      Induttanza della bobina mobile (Le)
      1.00 mH
      Frequenza di risonanza (Fs)
      51 Hz
      Fattore di merito meccanico (Qms)
      3.3
      Fattore di merito elettromagnetico (Qes)
      0.30
      Fattore di merito totale (Qts)
      0.28
      Massa del diaframma incl. la massa dell'aria (Mms)
      86 g
      Cedevolezza meccanica della sospensione (Cms)
      0.11 mm/N
      Superficie del cono (Sd)
      700 cm²
      Volume di spostamento (Vd)
      490 cm³
      Prodotto BL (BL)
      22 Tm
      Volume equivalente di cedevolezza (Vas)
      78 L
      Escursione lineare massima (Xmax)
      7 mm
      Perdite meccaniche del driver (Rms)
      8.3 Kg/s
      Bobina mobile doppia
      DUO double layer in/out copper voice coil
      Materiale del magnete
      Neodymium
      Diametro esterno complessivo
      359 mm
      Profondità complessiva
      166 mm
      Diametro del ritaglio del pannello frontale
      323 mm
      Diametro del cerchio dei fori di montaggio
      342 mm
      # Numero di fori di montaggio
      8
      Diametro dei fori di montaggio
      6.5 mm
