      Descrizione del prodotto Accuton C90-6-078 Woofer a Gamma Media

      The Accuton C90-6-078 is a high-performance 5-inch ceramic midrange driver designed for demanding audiophile applications. Engineered with precision and utilizing advanced materials, it delivers transparent, low-distortion performance ideal for high-end home audio systems.



      Highlights of the Accuton C90-6-078

      • Ultra-hard ceramic dome with anti-resonant cutout fills for damping 8 kHz resonance
      • FEA-optimized overhung motor with 38 mm aluminium voice coil former
      • Low-loss fabric surround and thin spider for high linearity
      • Vented pole piece and spider for improved thermal and mechanical performance



      Product details Accuton C90-6-078

      Accuton C90-6-078 Midrange Driver



      The Accuton C90-6-078 is a 130 mm (5-inch) midrange loudspeaker unit featuring a highly rigid ceramic dome, optimized to minimize resonances through specialized cutout fills. These design elements effectively dampen the dome’s 8 kHz resonance, contributing to a clean and uncolored midrange response. Built around a FEA-optimized overhung motor structure, the driver utilizes a 38 mm aluminium voice coil former and a copper voice coil for low energy storage and efficient heat transfer. Its sensitivity of 88 dB and a linear excursion of ±3 mm make it suitable for integration in high-fidelity systems. The C90-6-078 covers a frequency range from 200 Hz to 5,000 Hz, ideal for 3-way or active multi-driver configurations in audiophile-grade loudspeaker designs. The soft fabric surround and thin spider provide excellent centering with minimal mechanical resistance, ensuring high linearity throughout the operating range. The vented pole piece and spider further support thermal stability and mechanical ventilation during extended use. With a nominal impedance of 6.4 Ohms and robust 120W power handling, this driver stands out as a premium midrange solution for home stereo or studio monitor applications.

      Show more

      Specifiche

      Numero dell'articolo:
      C90-6-078
      EAN
      9501255562233
      Tipo di woofer
      Mid-range Woofer
      Diametro nominale
      5"
      Gestione della potenza (RMS)
      120 Watts
      Sensibilità (SPL a 1m / 2,83V)
      88 dB
      Risposta in frequenza
      200-5.000 Hz
      Diametro della bobina mobile
      38 mm
      Resistenza DC (Re)
      6.4 Ω
      Induttanza della bobina mobile (Le)
      0.18 mH
      Frequenza di risonanza (Fs)
      100
      Fattore di merito meccanico (Qms)
      2.4
      Fattore di merito elettromagnetico (Qes)
      1.52
      Fattore di merito totale (Qts)
      0.92
      Massa del diaframma incl. la massa dell'aria (Mms)
      6.96
      Cedevolezza meccanica della sospensione (Cms)
      0.36
      Superficie del cono (Sd)
      86 cm²
      Prodotto BL (BL)
      4.3 Tm
      Volume equivalente di cedevolezza (Vas)
      3.9 Liters
      Perdite meccaniche del driver (Rms)
      1.86
      Supporto della bobina mobile
      Aluminium
      Diametro esterno complessivo
      130 mm
      Profondità complessiva
      64.5 mm
      Diametro del ritaglio del pannello frontale
      102 mm
      Diametro del cerchio dei fori di montaggio
      110 mm
      # Numero di fori di montaggio
      4
      Diametro dei fori di montaggio
      4.5 mm
